Small But Powerful
Bring it home when you need without any inconvenience that it can be your mini PC and your portable storage device.
PEACE of MIND
- Easy to use and make life simple
Support Up To 8K Resolution
Cubi 5 allows you to enjoy the best experience of watching movie with your family or attending online conference call while working from home or learning professional tasks at home.
Bolt To The Next Power
Thunderbolt™ 4* brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all - delivering the fastest, most versatile connection to any dock, display, or data device & NAS.
Embracing a wide array of interface compatibilities so that you can edit, collaborate and share seamlessly
See More, Do More
With HDMI, DP, and Thunderbolt 4, Cubi 5 allows you to extend to three monitors to preview your E-commerce content & data at home or in the office, enhancing your efficiency.
MSI Cloud CenterFast, Secure & Wireless Backup
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS device faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.
MSI Center
The MSI Center takes optimization to the next level with easily adjustable system modes; it helps to prioritize & allocate the resource on your hand to accelerate the performance of those software which you work with everyday.
| General Information | |
| Manufacturer | MSI |
| Manufacturer Part Number | CU512M265BTAA |
| Manufacturer Website Address | http://www.msi.com |
| Brand Name | MSI |
| Product Line | Cubi 5 12M |
| Product Model | Cubi 5 12M-265BUS |
| Product Name | Cubi 5 12M-265BUS Barebone System |
| Product Type | Barebone System |
| Processor | |
| Number of Processors Installed | 1 |
| Processor Supported | Core i7 |
| Processor Supported | Core i5 |
| Processor Supported | Core i3 |
| Processor Type | Core i5 |
| Processor Generation | 12th Gen |
| Processor Model | i5-1235U |
| Processor Core | Dodeca-core (12 Core) |
| Processor Speed | 3.30 GHz |
| Maximum Turbo Speed | 4.40 GHz |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Total Number of Memory Slots | 2 |
| Storage | |
| Supported Storage Drive Interfaces | Serial ATA |
| Supported Storage Drive Interfaces | PCI Express 4.0 x4 |
| Supported Storage Drive Types | HDD |
| Supported Storage Drive Types | SSD |
| Controllers | |
| Controller Type | NVMe |
| Controller Type | Serial ATA |
| Display & Graphics | |
| Graphics Controller Model | Iris Xe Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.3 |
| I/O Expansions | |
| Number of Total Expansion Bays | 1 |
| Number of M.2 Interfaces | 1 |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 3.2 Gen 2 Ports | 4 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| DisplayPort | Yes |
| Number of Thunderbolt 4 Ports | 1 |
| Operating System | |
| Operating System Supported | Windows 11 Home |
| Operating System Supported | Windows 11 Pro |
| Power Description | |
| Maximum Power Supply Wattage | 65 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Mini PC |
| Height | 2.1" |
| Width | 4.9" |
| Depth | 4.9" |
| Weight (Approximate) | 1.21 lb |
| Miscellaneous | |
| Package Contents |
|
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
