EVERFOCUS
EVERFOCUS VANGUARDII8X4H NDAA 8 CH HYBRID DVR, NO HARD DRIVE, SUPPORTS 8 AHD/TVI/SD 8MP CAMERAS & 4 CH OF
Mfg Part Number: VANGUARDII8X4H , Item #: 5138739
Image may not reflect the actual item.
Price: $386.23
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Oct 08, 2025
No Sales Tax except these states
, PO and Wire.
Supports hybrid mode: Analog: Up to 8CH 8MP AHD/TVI/CVBS cameras IP: Up to 4CH 8MP IP cameras (up to 12CH if only IP cameras are connected) Megapixel resolution over standard coaxial / UTP cable
- Supports hybrid mode: Analog: Up to 8CH 8MP AHD/TVI/CVBS cameras IP: Up to 4CH 8MP IP cameras (up to 12CH if only IP cameras are connected)
- Megapixel resolution over standard coaxial / UTP cable
- Supports H.265 / H.264 compression format
- Supports cloud storage with Dropbox & Google Drive (Snapshot)
- Supports ONVIF 2.0 IP cameras
- Control methods: mouse / IR remote controller
- Remote configuration from built-in web interface
- Integrates with VANGUARD CMS
- Supports multi-language
- Supports mobile App: eFVMS App
Main Specification
| General Information | |
| Manufacturer | EverFocus Electronics Corporation |
| Manufacturer Part Number | VANGUARD II 8X4H |
| Manufacturer Website Address | http://www.everfocus.com |
| Brand Name | EverFocus |
| Product Line | VANGUARD |
| Product Name | VANGUARD II 8X4H |
| Product Type | Video Surveillance Station |
| Technical Information | |
| Total Number of Channels | 8 |
| Connectivity Technology | Wired |
| Recording Formats | 4K |
| HD Recording | Yes |
| System Components | Digital Video Recorder |
| Storage | |
| Hard Drive Capacity | 8 TB |
| Memory | |
| Standard Memory | 2 GB |
| Video | |
| Video Formats | H.264 |
| Video Formats | H.265 |
| Video Signal Format | PAL |
| Video Signal Format | NTSC |
| Maximum Resolution | 8MP |
| Maximum Frame Rate | 240 fps |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Interfaces/Ports | |
| USB | Yes |
| Composite Video In | Yes |
| Total Number of Audio In Ports | 8 |
| Total Number of Audio Out Ports | 1 |
| Number of VGA Out | 1 |
| HDMI | Yes |
| Power Description | |
| Power Consumption | 60 W |
| Physical Characteristics | |
| Height | 2" |
| Width | 14.9" |
| Depth | 12.5" |
| Weight (Approximate) | 4.63 lb |
| Miscellaneous | |
| TAA Compliant | Yes |
