TP LINK
TP LINK TP-Link NT SG2210MP Omada JetStream 10PT Gigabit Smart SWT 150W PoE Budget
Mfg Part Number: SG2210MP , Item #: 5129405
, PO and Wire.
Realize More Possibilities with Omada
JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+
TL-SG2210MP
Centralized Cloud Management
Omada SDN Platform Integration
Advanced L2 Features
L2/L3/L4 QoS, ACL, IGMP Snooping and More
Abundant Security Strategies
LAN Area Investment Protection
PoE+ Output
8 PoE+ Ports with Total 150 W Power Budget
Software Defined Networking (SDN) with Cloud Access
Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
| General Information | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | SG2210MP |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Brand Name | TP-Link |
| Product Line | JetStream |
| Product Model | TL-SG2210MP |
| Product Name | JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+ |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 10 |
| Modular | Yes |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+ |
| Port/Expansion Slot Details | 2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 2.0 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 4 |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.3az |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.1s |
| Networking Standards | IEEE 802.3af |
| Networking Standards | IEEE 802.3u |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.3ad |
| Networking Standards | IEEE 802.3i |
| Networking Standards | IEEE 802.1w |
| Networking Standards | IEEE 802.3at |
| Networking Standards | IEEE 802.3ab |
| Networking Standards | IEEE 802.1D |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.3z |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 150 W |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Power Source | Power Supply |
| Power Source | PoE+ |
| Power Source | AC |
| Power Consumption | 173.90 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Form Factor | Desktop |
| Height | 1.7" |
| Width | 11.6" |
| Depth | 7.1" |
| Miscellaneous | |
| Application/Usage | Retail |
| Application/Usage | Office |
| Application/Usage | Network |
| Application/Usage | Education |
