STARTECH
StarTech SWT D86A2-4-PORT-8K-KVM 4PT DP1.4 KVM Switch 8K 60Hz 4K 144Hz Retail
Mfg Part Number: D86A2-4-PORT-8K-KVM , Item #: 5061342
, PO and Wire.
Share and switch between two USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.
High-Resolution 8K 60Hz Video
This KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120x1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.
Customizable Switching
This Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling the other. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.
Universal Compatibility
The TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.
Reliable Performance
The durable metal housing helps prevent Electro-magnetic Interference (EMI). Overcurrent Protection (OCP) ensures peripherals don't overdraw power, reducing the occurrence of device dropouts or shutdowns.
| General Information | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | D86A24PORT8KKVM |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | KVM Switchbox |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Technical Information | |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Maximum Data Transfer Rate | 640 MB/s |
| Features | LED Indicator |
| Video | |
| Graphic Mode | 8K |
| Maximum Video Resolution | 7680 x 4320 |
| Interfaces/Ports | |
| USB | Yes |
| USB Standard | USB 2.0 |
| USB Standard | USB 3.2 |
| USB 2.0 | Yes |
| DisplayPort | Yes |
| Number of USB Ports | 10 |
| Number of DisplayPorts | 5 |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Power Description | |
| Input Current | 1 A |
| Input Voltage Range | 100 - 240 AC |
| Power Plug Type | Type M |
| Physical Characteristics | |
| Height | 1.7" |
| Width | 5.1" |
| Depth | 8.7" |
| Weight (Approximate) | 2.30 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
