VERTIV GXT5LI-5KL630RT3UXLN GXT5 LI 5KVA 208V L6-30P RT XL HV UPS
Mfg Part Number: GXT5LI-5KL630RT3UXLN , Item #: 5059893
Special Note: Feb 05, 2024
NCNR; If you do not have loading facility, please contact our CST for special handling service.
, PO and Wire.
The Vertiv Liebert GXT5 Lithium-Ion UPS protects critical IT applications against outages and various power disturbances. This online UPS offers the highest level of power conditioning and battery backup in server rooms, network closets, and other edge or distributed IT locations. Lithium-Ion batteries require fewer battery replacements and last up to 3x as long as traditional VRLA batteries reducing maintenance, labor, and replacement costs (resulting in the lowest TCO). The battery offers industry-leading runtime to protect critical equipment during an unexpected power loss. It also gives better performance at higher temperatures, supports up to 10 times more discharge cycles, and delivers faster recharge times. It is hot-swappable and user-replaceable, so you can easily replace it without disrupting power to connected equipment. The Integrated Maintenance Bypass Cabinet (MBC) allows the user to continue to power connected equipment even during UPS maintenance or replacement.
| General Information | |
| Manufacturer | Vertiv |
| Manufacturer Part Number | GXT5LI-5KL630RT3UXLN |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Brand Name | Vertiv Liebert |
| Product Series | GXT |
| Product Model | GXT5LI |
| Product Name | GXT5LI 5000 GV UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-30R |
| Receptacle Detail | 2 x NEMA L6-30R |
| Transfer Time | 0 ns |
| Phase | Single Phase |
| Application/Usage | Mission Critical Equipment |
| Application/Usage | Server Room |
| Application/Usage | Network Closet |
| Application/Usage | IT |
| Features | Built-in Bypass Switch |
| Power Description | |
| Load Capacity (VA) | 5000 VA |
| Load Capacity (Watt) | 4900 W |
| Input Voltage | 230 V AC |
| Output Voltage | 240 V AC |
| Waveform Type | Pure Sine Wave |
| Circuit Breaker | Yes |
| Output Power Factor | 0.98 |
| Display & Graphics | |
| Display | LCD/LED |
| Interfaces/Ports | |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Backup/Run Time (Full Load) | 11 Minute |
| Backup/Run Time (Half Load) | 25 Minute |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Physical Characteristics | |
| Height | 5.20" |
| Width | 16.90" |
| Depth | 35" |
| Rack Height | 3U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 103 lb |
| Miscellaneous | |
| Package Contents |
|
| Energy Star | Yes |
| Country of Origin | China |
| TAA Compliant | No |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Warranty | |
| Limited Warranty | 5 Year |
| Additional Warranty Information | 5-year warranty on UPS and batteries |
