Supermicro SV SSG-641E-E1CR36L 4U Xeon Dual LGA-4677 Max4TB DDR5 36x3.5 HS

Mfg Part Number:  SSG-641E-E1CR36L
Image may not reflect the actual item.
Price: $6,160.33
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Aug 23, 2025
No Sales Tax except these states
, PO and Wire.
Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number SSG641EE1CR36L
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line SuperServer
Product Model SSG-641E-E1CR36L
Product Name Storage SuperServer SSG-641E-E1CR36L
Product Type Server Barebone System
Processor
Number of Processors Supported 2
Processor Socket Socket LGA-4677
Processor Supported Xeon Silver
Processor Supported Xeon Bronze
Processor Supported Xeon Gold
Processor Supported Xeon Platinum
64-bit Processing Yes
Chipset
Chipset Manufacturer Intel
Chipset Model C741
Memory
Maximum Memory Supported 4 TB
Memory Technology DDR5 SDRAM
Total Number of Memory Slots 16
Storage
Supported Storage Drive Interfaces Serial ATA III
Supported Storage Drive Interfaces SAS-3
Supported Storage Drive Interfaces PCI Express
Supported Storage Drive Types HDD
Supported Storage Drive Types SSD
Controllers
Controller Type NVMe
Controller Type 12Gb/s SAS
Controller Type Serial ATA/600
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Ethernet Technology Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 38
Number of 3.5" Bays 36
Total Number of Expansion Slots 6
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 4
Number of M.2 Interfaces 2
Interfaces/Ports
Total Number of USB Ports 4
Number of USB 3.0 Ports 4
Network (RJ-45) Yes
Number of Network (RJ-45) Ports 3
Number of VGA Ports 1
Power Description
Input Voltage 230 V AC
Input Voltage 120 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1600 W
Thermal Design Power 270 W
Frequency 50 Hz
Frequency 60 Hz
Physical Characteristics
Color Family Silver
Product Color Silver
Form Factor Rack-mountable
Rack Height 4U
Height 7"
Width 17.2"
Depth 27.5"
Weight (Approximate) 65.50 lb
Miscellaneous
Package Contents
  • Storage SuperServer SSG-641E-E1CR36L
  • 1 x Super X13DEI-T Motherboard
  • 1 x 4U Chassis
  • 1 x 8 int 12Gb/s SAS3 ports, x8 Gen4, HBA - LP,122HDDw/exp,R
  • 1 x 8-port Mini SAS HD Int-to-Ext Cable Adapter W/LP Bracket
  • 1 x 2U 12-slot SAS3/SATA3 LFF Expander BPN, 4 of the 12-slots are hybrid ports also support NVMe Gen 4.,RoHS
  • 1 x 4U 24-Port LFF Expander Backplane support up to 16 SAS3/SATA3 and 8 SAS3/SATA3/NVMe Gen 4 Storage Media
  • 2 x 9" 4 PIN FAN PWS EXTENSION CORD, PBF
  • 1 x 4 Pin to 4 Pin I2C Cable, 65cm, 26AWG, 4 Wires, Pinout 1-1
  • 1 x Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM,
  • 2 x Slimline x4 (STR) to MiniSAS HD (STR) x4,85CM,100 OHM,R
  • 2 x Slimline x4 (STR) to Slimline x4 (STR),INT,85CM,100 OHM,
  • 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF
  • 2 x US POWER CORD 16AWG, PB FREE
  • 7 x PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,37CM,22AWG,5A/pin,RoHS
  • 1 x STD I/O shield for X13 server MB with venting holes
  • 1 x License key for enabling OOB BIOS management
  • 1 x 2U Active CPU Heat Sink for X13 Gen. Building Block Solution
  • 1 x 2U Passive CPU HS for X13 EGS and X14-SP BHS-SP Systems
  • 2 x 1U 1600W Redundant Titanium Power Supply 76mm width 27Pair,PBF
  • 1 x 4U support redundancy input powers and output over 2.6KW PDB
  • 7 80x80x38 mm, 13.5K RPM, Optional Middle Cooling Fan for 2U Ultra Series Servers (Hot-swappable Version of FAN-0162L4)
  • 1 x Chassis transfer board for SC826
  • 36 x Black gen 5.5 hot-swap 3.5" HDD tray
  • 1 x SC847B LP MB Tray assembly,HF,RoHS/REACH
  • 1 x set Rail set, quick/quick, default for 4U 17.2" W
  • 1 x Rail screw bag
  • 1 x SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 1 Year
Additional Warranty Information

Supermicro provides a three-year warranty for labor and one-year warranty for parts.
