HPE ProLiant DL360 Gen10 Plus server
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized.
The HPE ProLiant DL360 Gen10 Plus server supports the 3rd Generation Intel® Xeon® Scalable Processors with up to 40 cores, plus 3200 MT/s HPE DDR4 Smart Memory up to 4.0 TB per socket. Introducing PCIe Gen4 and Intel® Software Guard Extensions (SGX) support on the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server complements Gen10 reach by delivering premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.
General Information | |
Manufacturer | Hewlett Packard Enterprise |
Manufacturer Part Number | P69298005 |
Manufacturer Website Address | http://www.hpe.com |
Brand Name | HPE |
Product Line | ProLiant |
Product Series | DL360 G10 Plus |
Product Name | ProLiant DL360 G10 Plus Server |
Product Type | Server |
Processor | |
Number of Processors Supported | 2 |
Number of Processors Installed | 1 |
Processor Type | Xeon Silver |
Processor Generation | 3rd Gen |
Processor Model | 4310 |
Processor Core | Dodeca-core (12 Core) |
Processor Speed | 2.10 GHz |
Cache | 18 MB |
Chipset | |
Chipset Manufacturer | Intel |
Chipset Model | C621A |
Memory | |
Standard Memory | 32 GB |
Maximum Memory Supported | 2 TB |
Memory Technology | DDR4 SDRAM |
Error Checking | ECC |
Number of Occupied Memory Slots | 1 |
Intel Optane Memory Ready | Yes |
Signal Processing | Registered (Buffered) |
Controllers | |
Controller Type | NVMe |
Controller Model | NS204i-p |
I/O Expansions | |
Number of Total Expansion Bays | 9 |
Number of Internal 2.5" Bays | 8 |
Number of Media Drive Bays | 1 |
Number of SFF Bays | 8 |
Hot Swappable Bays | Yes |
Total Number of Expansion Slots | 2 |
PCI Express Details | 2 PCIe: 1 x16 FH, 1 x16 LP |
Display & Graphics | |
Graphics Memory Capacity | 16 MB |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
Interfaces/Ports | |
Total Number of USB Ports | 5 |
Number of USB 3.0 Ports | 5 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 4 |
VGA | Yes |
Number of VGA Ports | 1 |
Remote Management | Yes |
Remote Management Controller | HPE iLO 5 |
Operating System | |
Operating System Supported | Hyper-V |
Operating System Supported | Windows Server 2019 Datacenter |
Operating System Supported | Windows Server 2019 Essentials |
Operating System Supported | Windows Server 2016 Datacenter |
Operating System Supported | Windows Server 2022 Standard |
Operating System Supported | Windows Server 2022 Essentials |
Operating System Supported | Red Hat Enterprise Linux 7.9 |
Operating System Supported | Oracle Linux 8.2 |
Operating System Supported | Ubuntu 20.04 LTS x64 |
Operating System Supported | SUSE Linux Enterprise Server 12 SP5 |
Operating System Supported | Windows Server 2022 Datacenter |
Operating System Supported | Windows Server 2016 Essential |
Operating System Supported | SUSE Linux Enterprise Server 15 SP2 |
Operating System Supported | Oracle Linux |
Operating System Supported | Oracle Linux 7.9 |
Operating System Supported | Red Hat Enterprise Linux 8.2 |
Operating System Supported | Windows Server 2019 Standard |
Operating System Supported | Windows Server 2016 Standard |
Power Description | |
Input Voltage | 230 V AC |
Input Voltage | 120 V AC |
Number of Power Supplies Supported | 2 |
Number of Power Supplies Installed | 2 |
Plug/Connector Type | C13/C14 |
Maximum Power Supply Wattage | 800 W |
Redundant Power Supply | Yes |
Hot Swappable Power Supply | Yes |
Power Source | Power Supply |
Physical Characteristics | |
Form Factor | Rack |
Rack Height | 1U |
Height | 1.7" |
Width | 17.1" |
Depth | 29.2" |
Weight (Approximate) | 39.93 lb |
Miscellaneous | |
Package Contents |
|
Security Features |
|
Energy Star | Yes |
Environmentally Friendly | Yes |
Energy Efficiency Certification | ENERGY STAR 4.0 |
Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Warranty | |
Limited Warranty | 3 Year |
Additional Warranty Information | 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
