NETGEAR
NETGEAR GS108MX-100NAS 8PT GIG UM +1P 10G/MULTI-GIG UPLINK
Mfg Part Number: GS108MX-100NAS , Item #: 4966739
, PO and Wire.
Unlock the Potential of your Gigabit devices
The NETGEAR 8-port Gigabit Unmanaged Switches, GS108X and GS108MX, help businesses cost-effectively connect their network with powerful gigabit speeds.
The GS108MX features one 10G/Multi-Gig Ethernet port for non-blocking uplink while the GS108X features a 10G SFP+ port for non-blocking uplink over longer distances.
Both switches come with eight 1G Ethernet ports housed in a fanless metal case that can be placed on a desk or mounted on a wall. These switches are energy efficient, built to last, and rigorously tested to provide the reliability businesses need.
Highlights | Plug-and-Play
- Simple set up with no software to install or configuration needed and zero maintenance
10 Gigabit Uplink
- For the GS108X, the SFP+ fiber uplink offers an expanded, long-distance connection for more than 100m. Requires fiber transceiver.
- With the GS108MX the 10G/Multi-Gig uplink reduces network bottlenecks.
Flexible Mounting
- Wall-mount or desktop
Small Form Factor
- Compact design to fit in any small cabinet or wiring panel
High Quality and Reliable Performance
- Durable metal case and long product life (shown by MTBF numbers)
LED to indicate activity on each port
- Check port activity directly on the switch for network activity status.
Silent Switches
- Fanless quiet operation
Industry Leading Warranty
- Limited Lifetime Hardware Warranty
| General Information | |
| Manufacturer | Netgear, Inc |
| Manufacturer Part Number | GS108MX-100NAS |
| Manufacturer Website Address | http://www.netgear.com |
| Brand Name | Netgear |
| Product Line | Business |
| Product Model | GS108MX |
| Product Name | Business GS108MX Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Features | LED Indicator |
| Features | Plug and Play |
| Features | Energy Efficient |
| Interfaces/Ports | |
| Total Number of Network Ports | 9 |
| Uplink Port | Yes |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Port/Expansion Slot Details | 1 x 10 Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10GBase-T |
| Network Technology | 10/100/1000Base-T |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.3az |
| Management & Protocols | |
| Manageable | No |
| Reliability | |
| MTBF | 3514690 Hour |
| Power Description | |
| Power Source | Power Adapter |
| Power Consumption | 5.80 W |
| Physical Characteristics | |
| Product Material | Metal |
| Form Factor | Wall Mountable |
| Form Factor | Compact |
| Form Factor | Desktop |
| Height | 1.1" |
| Width | 9.3" |
| Depth | 4" |
| Weight (Approximate) | 1.27 lb |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Network |
| Application/Usage | Conference Room |
| Application/Usage | Office |
| Application/Usage | Small Business |
| Application/Usage | Classroom |
| Certifications & Standards |
|
| Warranty | |
| Limited Warranty | Lifetime |
