CISCO
CG113-4GW6B CISCO CATALYST WIRELESS GATEWAY, WIFI6, 4G LTE, DOMAIN B
Mfg Part Number: CG113-4GW6B , Item #: 4964607
, PO and Wire.
Built ground-up keeping in mind the hybrid-worker, the Cisco Catalyst Wireless Gateway CG113 is powered by the Cisco IOS CG operating system and provides office experience to home users with all-round security in a home-friendly form factor.
The Cisco Catalyst Wireless Gateway CG113 routers consist of the CG113-4GW6x and CG113-W6x models. The two models feature a low footprint teleworker-specific feature set and are managed centrally by Cisco Catalyst SD-WAN Manager.
The Catalyst Wireless Gateway CG113 platform delivers reliable connectivity to home users and provides high performance to reach both corporate and cloud-hosted applications. Users can concurrently use different types of traffic (voice, video, corporate applications) seamlessly and reliably with a cellular backup mechanism. Centralized zero-touch provisioning, configuration, monitoring, and troubleshooting are enabled with SD-WAN Manager, with a simplified, intuitive workflow for the network administrator. In addition, end-users can configure Home SSIDs, monitor their devices and access troubleshooting information through a new local Web User Interface.
| General Information | |
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CG1134GW6B |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Line | Catalyst |
| Product Series | CG113 |
| Product Model | CG113-4GW6B |
| Product Name | Catalyst CG113-4GW6B Wireless Router |
| Product Type | Wireless Router |
| Technical Information | |
| Wi-Fi Generation | Wi-Fi 6 |
| Memory Technology | DDR4 SDRAM |
| Standard Memory | 2 GB |
| Wireless Specifications | |
| Broadband Transmission Technology | Ethernet |
| Wireless LAN Standard | IEEE 802.11ax |
| Cellular Generation | 4G |
| Cellular Data Connectivity Technology | LTE |
| Total Number of Antennas | 4 |
| Number of Internal Antennas | 4 |
| Encryption Standard | SHA-1 |
| Encryption Standard | AES (256-bit) |
| Encryption Standard | AES (128-bit) |
| Encryption Standard | AES-CBC |
| Encryption Standard | AES |
| Encryption Standard | SHA-2 |
| Interfaces/Ports | |
| Total Number of Network Ports | 3 |
| Number of Network (RJ-45) Ports | 2 |
| USB | Yes |
| Number of Broadband (RJ-45) Ports | 1 |
| USB Standard | USB Type C |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Multi-SIM Supported | Yes |
| Number of SIM Card Supported | 2 |
| SIM Size Supported | Nano |
| Storage | |
| Flash Memory Capacity | 1 GB |
| Physical Characteristics | |
| Height | 7.1" |
| Width | 3.8" |
| Depth | 3.8" |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 1 Year |
