DATALOGIC

M3410-010200-07104 DATALOGIC MAGELLAN 3410VSI, DEFAULT CONFIGURATION, 1D/2D SCANNING, NO MOUNT, EUR

Mfg Part Number:  M3410-010200-07104
Image may not reflect the actual item.
Price: $839.19 + Free Shipping
Quantity:
More to Come
Last Updated: Sep 01, 2025
No Sales Tax except these states
, PO and Wire.

ON-COUNTER HIGH PERFORMANCE BAR CODE READER

The Magellan 3410VSi series of scanners continue the Datalogic tradition of high performance imaging for the point of sale. With the same cables, mounts and exterior plastics as the Magellan 3450VSi, the 3410VSi scanner is easy to integrate into existing installations. The new electronics platform allows the M3410VSi to power from a single 5V USB connection, providing outstanding performance and easy connection to any POS system.

With a large field of view and the capabilities of imaging, the 3410VSi scanners provide outstanding performance on hard-to-read bar codes and seamless reading of a wide variety of bar codes. This Magellan scanner enables both high speed sweep and presentation scanning techniques, ensuring maximum productivity and ergonomic ease, even with truncated (shortened), out-of-spec or poorly printed codes.

ENHANCING THE CUSTOMER EXPERIENCE

The optional Magellan Customer Service Scanner (CSS) enables retailers to easily engage their customers in mobile commerce programs, allowing them to scan bar codes from mobile phone screens or paper coupons while the cashier continues to scan regular items in parallel, resulting in a significant reduction in total transaction time.

ENTERPRISE FEATURES

Remote Management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director and Wavelink Avalanche. Additional capabilities are available with the Value Added Features included in every Magellan scanner.

Main Specification
General Information
Manufacturer Datalogic S.p.A
Manufacturer Part Number M3410-010200-07104
Manufacturer Website Address http://www.datalogic.com
Brand Name Datalogic
Product Line Magellan
Product Model 3410VSi
Product Name Magellan 3410VSi Barcode Scanner
Product Type Barcode Scanner
Technical Information
Connectivity Technology Cable
Scanning Capability 2D
Scanning Capability 1D
Barcode Symbology Supported

1D :

  • Autodiscriminates all standard 1D codes including GS1 DataBar linear codes.

2D :

  • Aztec Code
  • Data Matrix
  • QR Code

Stacked Codes:

  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
  • Micro PDF417
  • PDF417

Digital Watermarks:

  • Optional support for Digimarc Barcodes / GS1 DW Code


Light Source LED
Image Sensor Type Imager
Scanning Distance 8"
Features Checkpoint EAS
Features Ergonomic Design
Features Sensormatic EAS
Features Notification LED
Features Beep
Features Diagnostic Reporting
Cable Type Included Serial
Reading Angle (Skew) 75°
Reading Angle (Pitch) 65°
Reading Angle (Roll) 360°
Image Formats JPEG
Image Formats BMP
Maximum Ambient Light 86100 lux
Minimum Print Contrast 25%
Minimum Element Resolution (DataMatrix) 10 mil
Maximum Element Resolution (DataMatrix) 20 mil
Image Sensor Resolution 1280 x 800
Illumination Type LED
Air Electrostatic Discharge (+/-) 25kV
Interfaces/Ports
Host Interface Serial
Power Description
Maximum Operating Power Consumption 3.30 W
Environmental Conditions
Operating Temperature 50°F (10°C) to 104°F (40°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 5% to 95%
Physical Characteristics
Form Factor Desktop
Color Family Dual Color
Product Color Silver
Product Color Black
Durability Dust Resistant
Durability Water Resistant
Weight (Approximate) 1.32 lb
Miscellaneous
Ingress Protection (IP) Rating IP52
Application/Usage Retail
