DATALOGIC

QD2220-BKK1S DATALOGIC QUICKSCAN D2220, 1D, USB KIT, STAND, BLK

Mfg Part Number:  QD2220-BKK1S
Image may not reflect the actual item.
Price: $154.52 + Free Shipping
Quantity:
More to Come
Last Updated: Aug 31, 2025
No Sales Tax except these states
, PO and Wire.

TAILORED LINEAR IMAGING TECHNOLOGY

Today there is an increased trend towards 2D bar codes, however, linear bar codes are still widespread in Retail POS checkout applications. Long bar codes are also commonly used in a variety of applications including utility bills, document processing and packaging. These long barcodes are a challenge for full area imagers to read due to their narrow field-of-view and shorter depth-of-field.

THE MOST PROMPT RESPONSE AT THE POS CHECK-OUT

The QuickScan QD2200 imager is the 1D entry-level corded imager from Datalogic with a superior scanning performance in its category. It reliably reads any type of 1D barcode from up close to a distance with ease in capturing long bar codes

Unlike other devices on the market, this imager provides full control to the operator, from the linear aiming to the most prompt visual and audible good-read feedback. It seamlessly reads through plexiglass barriers and can scan electronic coupons from smartphone screens at an incredibly affordable price.

COMFORT AND RELIABILITY

Lightweight and easy to handle, the QuickScan QD2200 is very responsive at the pull of the trigger, providing a superior robustness for this class of products where the device is mostly stressed, because of the accurate design and quality of parts.

Offering simple configuration and ease of use, this robust entry-level scanner delivers continuous operation capabilities with no failures.

Finally, the QuickScan QD2200 imager will prove to be the best longterm choice, by cutting down-time, no read/misread management time, and service costs.

Main Specification
General Information
Manufacturer Datalogic S.p.A
Manufacturer Part Number QD2220BKK1S
Manufacturer Website Address http://www.datalogic.com
Brand Name Datalogic
Product Line QuickScan I
Product Series 2200
Product Model QD2220-BKK1S
Product Name QuickScan QD2220-BK Barcode Scanner
Product Type Barcode Scanner Kit
Technical Information
Connectivity Technology Cable
Scanning Capability 1D
Barcode Symbology Supported

1D / Linear Codes:

  • ? Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.
Light Source LED
Image Sensor Type Imager
Image Sensor Type CCD
Scan Mode Trigger
Scan Pattern Linear
Scanner Range Standard Range
Cable Type Included USB
Stand Included Yes
Reading Angle (Skew) 65°
Reading Angle (Pitch) 65°
Reading Angle (Roll) 45°
Motion Tolerance 40 in/s
Maximum Ambient Light 120000 lux
Drop Specification

Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface.

Minimum Print Contrast 15%
Minimum Element Resolution (Code 39) 4 mil
Maximum Element Resolution (Code 39) 20 mil
Illumination Type LED
Illumination Color Red
Interfaces/Ports
Host Interface USB
Power Description
Input Current 165 mA
Standby Current 40 mA
Environmental Conditions
Operating Temperature 32°F (0°C) to 122°F (50°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 0% to 95%
Physical Characteristics
Form Factor Handheld
Color Family Black
Product Color Black
Weight (Approximate) 4.34 oz
Miscellaneous
Package Contents
  • QuickScan QD2220-BK Barcode Scanner
  • USB Cable
  • Stand
Ingress Protection (IP) Rating IP42
Application/Usage Hospitality
Application/Usage Commercial Service
Application/Usage Industrial
Application/Usage Government
Application/Usage Retail
