Powered by Intel 10 nm processors
Intel's Quad-Core N5105 CPU comes clocked at 2.0 GHz with boost clocks of up to 2.9 Ghz for efficient content creation.
Efficient Cooling
The AS54 series now come with four M.2 slots for NVMe SSDs. The high performance of M.2 SSDs requires heat dissipation and the upgraded chassis reflects the needs of the four M.2 slots found inside. Specially designed cooling vents ensure installed SSDs remain cool and stay at their maximum performance while also remaining aesthetically pleasing.
Four M.2 Slots
The AS54 series come with four M.2 slots for caching, storage or both. Either use all slots for one purpose or mix and match depending on your needs.
Superfast 2.5-Gigabit Ethernet ports
The AS54 series, despite being extremely affordable, contains dual 2.5-Gigabit Ethernet for up to 5 Gbps of performance when combined using SMB multichannel.
Data Protection Starts with Storage
ASUSTOR understands that your data is priceless, therefore ASUSTOR NAS provides numerous options for protecting your data from a variety of threats. Your data is important and receives numerous levels of protection from the moment it is first stored on the NAS. Take advantage of a variety of data protection features found inside an ASUSTOR NAS, including, but not limited to RAID, easy automatic backups and snapshots. ASUSTOR recommends planning a holistic 3-2-1 backup solution to protect data easily, efficiently and effectively.
| General Information | |
| Manufacturer | ASUSTOR |
| Manufacturer Part Number | AS5404T |
| Manufacturer Website Address | http://www.asustor.com |
| Brand Name | ASUSTOR |
| Product Line | Nimbustor 4 Gen2 |
| Product Series | AS54 |
| Product Model | AS5404T |
| Product Name | Nimbustor 4 Gen2 AS5404T SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| Storage | |
| Number of Hard Drives Supported | 4 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 4 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 8 GB |
| Processor & Chipset | |
| Processor Manufacturer | Intel |
| Processor Type | Celeron |
| Processor Model | N5105 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 2 GHz |
| Memory | |
| Standard Memory | 4 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| Number of 2.5"/3.5" Bays | 4 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, 1+Hot Spare, 5+Hot Spare, JBOD |
| Interfaces/Ports | |
| Drive Interface | Serial ATA/600 |
| HDMI | Yes |
| Total Number of USB Ports | 3 |
| Number of USB 3.2 Gen 2 Ports | 3 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Software | |
| Operating System | ADM 4.2 |
| Management & Protocols | |
| Protocols | SNMP |
| Protocols | TFTP |
| Protocols | CIFS |
| Protocols | WEBDAV |
| Protocols | HTTPS |
| Protocols | SMB 3.0 |
| Protocols | AFP |
| Protocols | RSync |
| Protocols | DDNS |
| Protocols | SSL |
| Protocols | NFS |
| Protocols | SSL/TLS |
| Protocols | HTTP |
| Protocols | FTP |
| Protocols | SMB 2.0 |
| Protocols | TCP/IP |
| Protocols | iSCSI |
| Protocols | IPv6 |
| Protocols | LDAP |
| Protocols | SFTP |
| Protocols | SMB |
| Protocols | IPv4 |
| Protocols | SSH |
| Protocols | TLS |
| Power Description | |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Height | 6.7" |
| Width | 6.9" |
| Depth | 9.1" |
| Weight (Approximate) | 4.98 lb |
| Miscellaneous | |
| Package Contents |
|
| Warranty | |
| Limited Warranty | 3 Year |
