Key Features
Increase Performance for Application and Solid State Storage Architectures
The HPE B-series SN6700B Fibre Channel Switch delivers increased performance through a combination of improved throughput and low latency across 64Gb links in hyper-scale virtualization, large cloud infrastructures, and growing flash-based storage environments.
Improved performance of NVMe storage with 50% lower switching latency than Gen 6. Latency for locally switched ports is 460 ns including forward error correction (FEC).
With 56 SFP+ ports, it can scale up to 56 device ports for an aggregate throughput of 3.584Tb/s.
Ultra-dense and Highly Scalable
The HPE B-series SN6700B Fibre Channel Switch scales up to 56 Fibre Channel ports in an efficiently designed 1U form factor, delivering increased port density and space utilization for simplified scalability.
Each of the 56 SFP+ ports supports 8, 10, 16, 32, and 64Gb FC speeds.
Provides flexibility to utilize high-speed 64Gb and 32Gb optics on demand to meet growing data center needs and provide backward compatibility to older infrastructures.
| General Information | |
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | R6B05A#AC3 |
| Manufacturer Website Address | http://www.hpe.com |
| Brand Name | HPE |
| Product Series | B |
| Product Model | SN6700B |
| Product Name | SN6700B 64Gb 56/24 24-port 32Gb Short Wave SFP28 Integrated Fibre Channel Switch |
| Product Type | Fibre Channel Switch |
| Interfaces/Ports | |
| Number of Fibre Channel Ports | 56 |
| Media & Performance | |
| Data Transfer Rate | 64 Gbit/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 56.0 |
| Expansion Slot Type | SFP28 |
| Power Description | |
| Redundant Power Supply | Yes |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 14" |
| Weight (Approximate) | 15.81 lb |
