OUR MOST POWERFUL MOBILE WORKSTATIONS
Fusing the portability of ThinkPad with the power of a workstation, P Series laptops feature ISV-certified applications, lightning-fast graphics & processing, and more cutting-edge technology to handle your compute-intensive needs - in a surprisingly thin, light package.
| General Information | |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 21FV0022US |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Brand Name | Lenovo |
| Product Line | ThinkPad |
| Product Series | P1 Gen 6 |
| Product Model | 21FV0022US |
| Product Name | ThinkPad P1 Gen 6 21FV0022US Notebook |
| Product Type | Notebook |
| Technical Information | |
| Release Month | June |
| Release Year | 2023 |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i7 |
| Processor Generation | 13th Gen |
| Processor Model | i7-13800H |
| Processor Core | Tetradeca-core (14 Core) |
| Processor Threads | 20 |
| Processor Speed | 2.50 GHz |
| Maximum Turbo Speed | 5.20 GHz |
| L3 Cache | 24 MB |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Supported System Memory | 96 GB |
| System Memory Technology | DDR5 SDRAM |
| System Memory Speed | 5600 MHz |
| System Memory Form Factor | SODIMM |
| Installed Slot Memory | 32 GB |
| Installed Slot Memory Configuration | 1 x 32GB |
| Total Number of Memory Slots | 2 |
| Number of Occupied Memory Slots | 1 |
| Memory Card Supported | SD |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express 4.0 |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Screen Size | 16" |
| Display Screen Technology | In-plane Switching (IPS) Technology |
| Standard Refresh Rate | 165 Hz |
| Screen Mode | WQXGA |
| Screen Resolution | 2560 x 1600 |
| Brightness | 500 Nit |
| Color Gamut | 100% sRGB |
| Touchscreen | No |
| Graphics Controller Manufacturer | NVIDIA |
| Graphics Controller Model | RTX 3500 |
| Graphics Memory Capacity | 12 GB |
| Graphics Memory Technology | GDDR6 |
| Graphics Memory Accessibility | Dedicated |
| Network & Communication | |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Wi-Fi Generation | Wi-Fi 6E |
| Cellular Data Connectivity Technology | EDGE |
| Wimax | No |
| Bluetooth | Yes |
| WWAN Supported | No |
| Near Field Communication | No |
| Built-in Devices | |
| Camera Privacy Shutter | Yes |
| Front Camera/Webcam | Yes |
| Infrared Camera | Yes |
| Finger Print Reader | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Network (RJ-45) | No |
| Headphone/Microphone Combo Port | Yes |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Operating System Architecture | 64-bit |
| Input Devices | |
| Keyboard Backlight | Yes |
| Keyboard Localization | English (US) |
| Battery Information | |
| Number of Cells | 4-cell |
| Battery Chemistry | Lithium Polymer (Li-Polymer) |
| Battery Energy | 90 Wh |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Maximum Power Supply Wattage | 230 W |
| AC Adapter Frequency | 60 Hz |
| AC Adapter Frequency | 50 Hz |
| USB Power Delivery Support | Yes |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Cover Material | Aluminum |
| Cover Material | Glass Fiber Reinforced Polymer (GFRP) |
| Cover Material | Carbon Fiber Reinforced Polymer (CFRP) |
| Height | 0.69" |
| Width | 14.2" |
| Depth | 10" |
| Weight (Approximate) | 4.10 lb |
| Miscellaneous | |
| Package Contents | |
| Charger Included | Yes |
| Features | Anti-glare Screen |
| Windows Hello Compatible | Yes |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) |
| Environmental Certification | ENERGY STAR 8.0 |
| Environmental Certification | TCO Certified 9.0 |
| Energy Efficiency Certification | ENERGY STAR 8.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information |
|
