ASUS
ASUS SY PN53-SYS735PX1TD0 Mini PC Ryzen7 6800H 32GB 512GB Radeon 680M W11P RTL
Mfg Part Number: PN53-SYS735PX1TD0 , Item #: 4850152
, PO and Wire.
Ultra-compact Mini PC provides flexible, comprehensive solutions
ASUS ExpertCenter PN53 is no lightweight when it comes to performance. It harnesses the power of the latest AMD Ryzen™ 6000 and 7000 Series processor combined AMD Radeon™ 600M series graphics, and can accommodate multiple storage combinations. There's also two ultrafast PCIe®Gen 4 SSD slots and DDR5 support to ensure fast boot times and rapid app loads.
System & CPU Performance
PN53 delivers a system performance uplift of up to 10% better performance in daily multitask computing, comparing to previous generation - providing powerful computing capacity and enabling easy multitasking and smooth operation.
Graphics Performance
ExpertCenter PN53 gets a significant graphical boost with Radeon™ Graphics to deliver crisp, clear visuals that are way ahead of its class. It delivers a marked improvement, raising its score from 55% in 3DMark Fire Strike and increasing 49% 3DMark Night Raid performance benchmarks.
Ultrafast PCIe®4.0 SSD
PCIe 4.0 doubles the data transfer rate of the prior PCIe 3.0 standard. ExpertCenter PN53 support one PCIe Gen4 x4 SSD to deliver greater data performance and lower latency.
Versatile USB 4 Type-C | Power Delivery
The Power Delivery (PD) function can either receive power from a supported display* or supply power to mobile devices.
Superfast data transfers
Experience up to 40 Gbps data transmission speeds with USB
DisplayPort™
Enjoy up to 8K @ 30 Hz video output
Faster and Better DDR5 RAM
ASUS ExpertCenter PN53 is powered by the new AMD 6000 and 7000 Series CPU supporting the next gen memory - DDR5. With DDR5 4800MHz memory that is 1.5X faster and 8% more energy efficient than DDR4 3200MHz memory, PN53 provides excellent performance for daily computing tasks.
4K Resolution & Quad Display Support
Integrated AMD Radeon 600M series graphics enable ExpertCenter PN53 to display stunning 4K UHD videos and imagery. With HDMI, USB-C DisplayPort and a configurable port that can be specified for video signal output, PN53 lets you extend your workspace across up to four displays.
Ultra-realistic 8K Visuals
ExpertCenter PN53 supports stunning 8K UHD visuals via USB 4 or the configurable video output ports for detail four times greater than 4K, or a remarkable 16 times that of traditional FHD visuals. PN53 is capable of pumping out 8K imagery at 30 Hz via USB 4 or DisplayPort 1.4; or up to 60 Hz through HDMI 2.1* to bring images to life.
| General Information | |
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | PN53-SYS735PX1TD0 |
| Manufacturer Website Address | http://usa.asus.com |
| Brand Name | Asus |
| Product Line | ExpertCenter |
| Product Series | PN53 |
| Product Model | PN53-SYS735PX1TD0 |
| Product Name | ExpertCenter PN53-SYS735PX1TD0 Desktop Computer |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | AMD |
| Processor Type | Ryzen 7 |
| Processor Model | 6800H |
| Processor Speed | 3.20 GHz |
| Maximum Turbo Speed | 4.70 GHz |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 32 GB |
| Memory Technology | DDR SDRAM |
| Storage | |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | AMD |
| Graphics Controller Model | Radeon Graphics |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | RTL8125BG-CG |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 7 |
| Number of USB4 Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 5 |
| Number Of Ethernet Ports | 1 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Mini PC |
| Height | 2.3" |
| Width | 4.7" |
| Depth | 5.1" |
| Weight (Approximate) | 1.98 lb |
| Miscellaneous | |
| Package Contents |
|
| Features | Security Slot |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
