SIMPLY NUC

SIMPLY NUC 91M-9GG5-0C1 NUC13TZI5 8GB 256GBP4 W11P

Mfg Part Number:  91M-9GG5-0C1
Image may not reflect the actual item.
Price: $1,137.22 + Free Shipping
Quantity:
More to Come
Last Updated: Jun 26, 2025
No Sales Tax except these states
, PO and Wire.

Evolve your Mini PC Experience

The Topaz 3 NUC harnesses Intel's latest 13th Gen Raptor Lake 1340P Processor with Iris Xe graphics to provide the most crisp computing experience to date. With up to 64GB of DDR4- 3200 memory and up to 10TB of M.2 storage, Topaz 3 has the capabilities you need to evolve your mini PC experience or corporate infrastructure to the latest and greatest technology available. Intel's 13th Gen 1340P processor ushers a host of new and improved features including increased core counts and an upgraded Intel® Thread Director to increase both your efficiency and your productivity.

Crystal Clear, Clean & Secure Computing

From a home theater to a digital signage kiosk, the Intel® Iris Xe Graphics in Topaz 3 have you covered. With support for up to four 4K displays, you can enjoy crisp visuals from every angle. Take advantage of super-fast networking with dual 2.5Gb LAN ports and onboard TPM 2.0, giving you a robust and secure connection to your home or office network, or ditch the cabling and go wireless with Wi-Fi 6E and Bluetooth 5.3 for that sleek setup look, without sacrificing performance and reliability.

The Number One Choice for your Next Mini PC

Topaz 3 offers a plethora of customization options while maintaining that 4x4 footprint people love. From Gen4 PCIe drives, to I/O options like additional USB ports and serial adapters via the replaceable lid, you have the versatility you need to meet your use case. The Topaz 3 NUC with a 13th Gen Intel® Core 1340P Processor is the number one choice for your mini PC needs for both the home and the office, so get yours, today.

Main Specification
General Information
Manufacturer SimplyNUC
Manufacturer Part Number 91M-9GG5-0C1
Manufacturer Website Address http://www.simplynuc.co.uk
Brand Name SimplyNUC
Product Line Topaz 3
Product Model NUC13TZi5
Product Name Topaz 3 NUC13TZi5 Desktop Computer
Product Type Desktop Computer
Processor
Processor Manufacturer Intel
Processor Type Core i5
Processor Generation 13th Gen
Processor Model i5-1340P
Processor Core Dodeca-core (12 Core)
Maximum Turbo Speed 4.60 GHz
Chipset
Chipset Manufacturer Intel
Memory
Standard Memory 8 GB
Maximum Memory Supported 64 GB
Memory Technology DDR4 SDRAM
Total Number of Memory Slots 2.0
Storage
Total Solid State Drive Capacity 256 GB
Solid State Drive Interface PCI Express NVMe 4.0 x4
SSD Form Factor M.2
Display & Graphics
Graphics Controller Manufacturer Intel
Graphics Controller Model Iris Xe Graphics
Graphics Memory Technology DDR4 SDRAM
Graphics Memory Accessibility Shared
Network & Communication
LAN Model i225-LM
Ethernet Technology 2.5 Gigabit Ethernet
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ax
Bluetooth Yes
Interfaces/Ports
HDMI (Rear) Yes
Total Number of USB Ports 6
Number of USB 3.2 Gen 2 Ports 4
USB Type-C (Front) Yes
USB Type-C Detail 2x USB 3.2 Gen2 Type-C
Number Of Ethernet Ports 2
Number of DisplayPort Outputs (Rear) 1
DisplayPort (Rear) Yes
Operating System
Operating System Platform Windows
Operating System Windows 11 Pro
Power Description
Maximum Power Supply Wattage 90 W
Physical Characteristics
Form Factor Mini PC
Height 1.9"
Width 4.5"
Depth 4.5"
Miscellaneous
Package Contents
  • Topaz 3 NUC13TZi5 Desktop Computer
  • Power Adapter
Features Security Slot
Environmentally Friendly Yes
Environmental Compliance Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 3 Year
Additional Warranty Information 3-yr Warranty and Support Service
