KRAMER 91-00017599 PORTABLE DOCKING STATION - ADAPTER USB TYPE-C TO USB TYPE-C/HDMI/DP/RJ45/USB/PD/
Mfg Part Number: 91-00017599 , Item #: 4792761
Image may not reflect the actual item.
Price: $229.54
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Sep 13, 2026
No Sales Tax except these states
, PO and Wire.
KDock-5 is a USB-C hub multiport adapter. KDock-5 can connect your USB-C device to HDMI™, DisplayPort video outputs, 3 USB 3.0 ports, an Ethernet port, an audio and microphone port, and USB-C charging pass-through port (1:8). KDock-5 is ideal as a personal work station at the office/or at home, and for small meeting rooms or huddle spaces
Main Specification
| General Information | |
| Manufacturer | Kramer Electronics LTD |
| Manufacturer Part Number | 91-00017599 |
| Manufacturer Website Address | http://www.kramerelectronics.com |
| Brand Name | Kramer |
| Product Line | KDock-5 |
| Product Name | KDock-5 USB−C Hub Multiport Adapter |
| Product Type | Docking Station |
| Technical Information | |
| Connectivity Technology | Wired |
| Charging Capability | Yes |
| Device Supported | Router |
| Device Supported | Headphone |
| Device Supported | Keyboard |
| Device Supported | Hard Drive |
| Device Supported | Mouse |
| Device Supported | Notebook |
| Features | Power Delivery Pass-through |
| Management Features | Wake-on-LAN |
| Management Features | PXE Boot |
| Management Features | MAC Address Pass-through |
| Number of Displays Supported | 2 |
| Screen Mode Supported | 4K |
| Supported Resolutions | 3840 x 2160 |
| Maximum Data Transfer Rate | 640 MB/s |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Host Interface | USB Type C |
| Total Number of USB Ports | 5 |
| Number of USB 3.0 Ports | 3 |
| USB Type-A | Yes |
| Number of USB Type-A Ports | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB: On a female USB type-C connector for charging (100W max), 1 x USB: On a female USB type-C connector for host connection, 1 x USB 3.0: On female USB type-C connectors (5V/0.9A) |
| Number of USB Type-C Ports | 3 |
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 1 |
| Headphone/Microphone Combo Port | Yes |
| HDMI | Yes |
| Number of HDMI Outputs | 1 |
| USB Power Delivery | 100W |
| Software | |
| Operating System Supported | Windows |
| Operating System Supported | macOS |
| Physical Characteristics | |
| Form Factor | Portable |
| Height | 0.75" |
| Width | 6.46" |
| Depth | 2.52" |
| Weight (Approximate) | 6.14 oz |
