Riptide is named after a specific kind of water current with strong waves that occurs in the ocean, representing the philosophy of sea's double-side, calm and unlimited strength. Built around powerful gaming-related features, the Riptide has given a powerful smash and immersed users in the sense of stability.
Featuring sturdy components and completely smooth power delivery to the CPU, offering enhanced performance for gamers.
Derived from the "built for stable and reliable" designing concept, ASRock does not compromise on any details. This motherboards is built with low-loss materials, enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance by enabling the pre-tested profiles. Make sure the memory modules are Intel®XMP/AMD EXPO™ capable and overclocking can be made so affordable, satisfying and absolutely no sweat at all.
Due to the unique electrical architecture of DDR5 DIMM, there's a high risk of damaging the memory module if AC power isn't disconnected properly during removal or installation. To prevent this, ASRock has implemented a trouble free protection circuit on every DDR5 motherboard, lowers the risk of damaging your memory module.
The reinforced steel slot is capable of supporting PCI Express 4.0 standard. The various benefits include:
? Extra anchor points
? Stronger latch
? Ensure signal stability
? Make sure heavy graphics cards to be well-installed.
Whether you are using headphones, a headset, external or internal speakers, via USB, Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant and rich with details.
In addition to the built-in RGB illumination, it also features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across thePolychrome RGB Sync-certifiedaccessories to create their own unique lighting effects.
Supports PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.
The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you'll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.
General Information | |
Manufacturer | ASRock, Inc |
Manufacturer Part Number | B760MPGRIPTIDE |
Manufacturer Website Address | http://www.asrock.com |
Brand Name | ASRock |
Product Model | B760M PG RIPTIDE |
Product Name | B760M PG RIPTIDE Gaming Desktop Motherboard |
Product Type | Gaming Desktop Motherboard |
Processor & Chipset | |
Chipset Manufacturer | Intel |
Chipset Model | B760 |
Total Processor Supported | 1 |
Processor Socket | Socket LGA-1700 |
Processor Generation Supported | 12th Gen |
Processor Generation Supported | 13th Gen |
Processor Supported | Core |
Memory | |
Number of Memory Slots | 4 |
Memory Form Factor | UDIMM |
Memory Form Factor | DIMM |
Maximum Memory Supported | 192 GB |
Memory Technology | DDR5 SDRAM |
Memory Speed Supported | 4000 MHz |
Memory Speed Supported | 4400 MHz |
Memory Speed Supported | 5600 MHz |
Memory Speed Supported | 7200 MHz |
Memory Speed Supported | 4800 MHz |
Memory Speed Supported | 3600 MHz |
Memory Speed Supported | 6000 MHz |
I/O Controller | |
Controller Type | Serial ATA/600 |
RAID Supported | Yes |
RAID Levels | 1 |
RAID Levels | 10 |
RAID Levels | 5 |
RAID Levels | 0 |
Video | |
Onboard Video | CPU Dependent Video |
Audio | |
Audio Channels | 7.1 |
Network & Communication | |
Gigabit Ethernet | Yes |
2.5Gigabit Ethernet | Yes |
I/O Expansions | |
PCI Express Standard | PCI Express 4.0 |
Total Number of PCI Express Slots | 2 |
Number of PCI Express x1 Slots | 1 |
Number of PCI Express x16 Slots | 1 |
Interfaces/Ports | |
Total Number of USB Ports | 8 |
Number of USB 2.0 Ports | 4 |
Number of USB 3.2 Gen 1 Type-A Ports | 3 |
HDMI | Yes |
HDMI Version | 2.1 |
DisplayPort | Yes |
Number of Network (RJ-45) Ports | 1 |
Onboard Interfaces | |
Number of SATA Interfaces | 4 |
Number of M.2 Interfaces | 2 |
Total Number of Onboard USB Ports | 5 |
Number of Onboard USB 2.0 Ports | 2 |
Physical Characteristics | |
Form Factor | Micro ATX |
Width | 9.6" |
Depth | 9.6" |
