, PO and Wire.
This affordable and compact box camera delivers 2 MP resolution with superb image quality even in low light conditions. Designed as a visible deterrent, it helps discourage trespassing and other unwanted activities.
More bang for your buck
This affordable Axis M-line camera includes a built-in microphone and audio recording, letting you hear and register sound in a fixed area. Thanks to support for PoE and redundant DC power, you get flexible installation, and your data is safeguarded in the event of a power outage. It includes signed firmware and secure boot to ensure only authorized firmware is installed and that the firmware hasn't been compromised. And, Axis Zipstream with support for H.264/H.265 significantly reduces bandwidth and storage requirements. Furthermore, it comes with AXIS Object Analytics preinstalled, so you can detect and classify humans and vehicles.
Great image quality even in low light
With 2 MP resolution at up to 30 fps, AXIS M1135 Mk II delivers superb video quality even in low light conditions. Featuring Axis Lightfinder it offers images in true colors even in low light. And, with Axis Forensic WDR you get clarity even when there's both dark and light areas in the scene. Ideal for various surveillance situations, it includes a CS-mount with support for motorized i-CS lenses, enabling remote zoom. Use our lens calculator to select a lens that meets your specific requirements.
Designed for deterrence
Designed to act as a deterrent, AXIS M1135 Mk II lets potential offenders know you're watching and helps prevent unwanted activities. This compact box camera provides a clearly visible, fixed angle of view, making it easy to see exactly where the camera's pointing and allowing you to record both audio and video in a precisely defined area. And, thanks to edge-to-edge technology it can be connected to Axis speakers, such as an Axis ceiling speaker.
| General Information | |
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 02580-001 |
| Manufacturer Website Address | http://www.axis.com |
| Brand Name | AXIS |
| Product Series | M11 |
| Product Model | M1135 Mk II i-CS |
| Product Name | M1135 Mk II Box Camera |
| Product Type | Network Camera |
| Technical Information | |
| Recording Formats | Full HD |
| HD Recording | Yes |
| Display & Graphics | |
| Image Sensor Type | RGB CMOS |
| Color Supported | Color |
| Field of View | Horizontal field of view: 101°-33° Vertical field of view: 53°-18° |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Video Formats | H.264B (MPEG-4 Part 10/AVC) |
| Video Formats | H.264H |
| Video Formats | H.265 (MPEG-H Part 2/HEVC) |
| Video Formats | H.264M (MPEG-4 Part 10/AVC) |
| Video Formats | H.264H (MPEG-4 Part 10/AVC) |
| Video Formats | Zipstream |
| Video Formats | Motion JPEG |
| Video Formats | H.265 |
| Video Formats | H.264 |
| Video Formats | H.264B |
| Video Formats | H.264M |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 3.50 mm |
| Maximum Focal Length | 10 mm |
| Lens Included | Yes |
| Lens Mount Type | CS-Mount |
| Maximum Aperture | f/1.4 |
| Optical Zoom | 2.9x |
| Exposure | |
| Shortest Shutter Speed | 1/33500 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 28 V DC |
| Power Source Type | DC |
| Power Source Type | PoE |
| Physical Characteristics | |
| Mount Type | Tripod Mount |
| Mount Type | Screw Mount |
| Form Factor | Box |
| Color Family | Dual Color |
| Product Color | Black |
| Product Color | White |
| Height | 2.5" |
| Width | 2.8" |
| Depth | 5.9" |
| Weight (Approximate) | 8.47 oz |
| Environmental Conditions | |
| Minimum Operating Temperature | -4°F (-20°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 85% |
| Miscellaneous | |
| Features | Human Detection |
| Features | Built-in Microphone |
| Features | Motion Detection |
| Features | Vehicle Detection |
| Features | Day/Night |
| Features | Active Tampering Alarm |
| Features | Wide Dynamic Range |
| Features | Audio Detection |
| Features | Video Content Analytics |
| Features | Audio Compression |
| Features | Face Detection |
