QSW-M2106R-2S2T-US QNAP RACKMOUNT SWITCH QSW-M2 06R-2S2T-US MANAGEMENT SWITCH 6PORT

The QSW-M2106R-2S2T is a Layer 2 Web Managed Switch with two 10GbE SFP+ fiber ports, two 10GbE RJ45 ports and six 2.5GbE RJ45 ports. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M2106R-2S2T offers flexible deployment in hybrid high-speed network environments and provides an entry-level network management solution. With a half-width design, two QSW-M2106R-2S2T can be installed in a 1U rack space for space-saving.

10GbE connectivity

Includes two 10GbE SFP+ fiber ports (Backward compatible with 1G SFP) and two 10GbE RJ45 ports, compatible with NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M) for high-speed networks.

2.5GbE connectivity

Six 2.5GbE RJ45 ports allow you to immediately multiply your network speed by 2.5 times while using existing Cat 5e cables.

User-friendly management interface

The QNAP Switch System (QSS) is easy to use and provides an overview dashboard, port management and setting guide, making central network management intuitive.

Layer 2 network

Provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for IT staff to efficiently control network bandwidth and enhance security.

RSTP

One of the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). Easily and efficiently deploy small/medium-scale networks that support expansion, redundancy, and loop prevention.

Online firmware update

QSS can be updated with just one click, helping IT staff ensure their network security.

General Information
Manufacturer	QNAP Systems
Manufacturer Part Number	QSW-M2106R-2S2T-US
Manufacturer Website Address	http://www.qnap.com
Brand Name	QNAP
Product Model	QSW-M2106R-2S2T
Product Name	10GbE and 2.5GbE Layer 2 Web Managed Switch for SMB Network Deployment
Product Type	Ethernet Switch
Interfaces/Ports
Total Number of Network Ports	8
Modular	Yes
Network (RJ-45)	Yes
Port/Expansion Slot Details	6 x 2.5 Gigabit Ethernet Port
Port/Expansion Slot Details	2 x 10 Gigabit Ethernet Port
Port/Expansion Slot Details	2 x 10 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported	Optical Fiber
Media Type Supported	Twisted Pair
Ethernet Technology	10 Gigabit Ethernet
Ethernet Technology	2.5 Gigabit Ethernet
Network Technology	2.5GBase-T
Network Technology	10GBase-X
Network Technology	10GBase-T
I/O Expansions
Total Number of Expansion Slots	2.0
Expansion Slot Type	SFP+
Number of SFP+ Slots	2
Network & Communication
Layer Supported	2
Networking Standards	IEEE 802.3
Networking Standards	IEEE 802.1w
Networking Standards	IEEE 802.3ab
Networking Standards	IEEE 802.3ae
Networking Standards	IEEE 802.1p
Networking Standards	IEEE 802.1ab
Networking Standards	IEEE 802.1ad
Networking Standards	IEEE 802.1Q
Networking Standards	IEEE 802.3z
Networking Standards	IEEE 802.3u
Networking Standards	IEEE 802.3x
Networking Standards	IEEE 802.3az
Management & Protocols
Manageable	Yes
Power Description
Input Voltage	230 V AC
Input Voltage	120 V AC
Frequency	60 Hz
Frequency	50 Hz
Power Source	Power Supply
Power Consumption	40 W
Physical Characteristics
Form Factor	Rack-mountable
Height	1.7"
Width	8.1"
Depth	9.8"
Weight (Approximate)	3.37 lb
Miscellaneous
Package Contents	10GbE and 2.5GbE Layer 2 Web Managed Switch For SMB Network Deployment Power Cord Rackmount Kit Quick Installation Guide (QIG)
Warranty
Limited Warranty	2 Year
