PTZOPTICS
PT20X-4K-GY-G3 PTZOptics Move 4K a third generation PTZ camera featuring 20X Optical Zoom 4K Resolution at 60fps and a 60.7 HFOV in Gray. Supports simultaneous IP Video (NDI HX3 SRT RTMPS RTSP) Power or Included Universal Power Supply
Mfg Part Number: PT20X-4K-GY-G3 , Item #: 4772955
, PO and Wire.
Precision. Clarity. Power.
Experience the cutting-edge prowess of PTZOptics Move 4K, boasting 4K 60fps auto-tracking, simultaneous outputs, and versatile control options. Seamlessly integrate with leading video production software like OBS, vMix, and Wirecast for an unparalleled live streaming experience.
Auto-Tracking & Auto-Framing: Enable auto-tracking or auto-framing, perfect for education, conferences, live broadcasts, and more.
Multiple Control Options: IR remote, network connection, RS-232, RS-485, Web UI, PTZ Control App, USB port, and Camera Management Platform.
Simultaneous Outputs: NDI, USB, & IP with either SDI or HDMI
4K Ultra HD: Next generation SONY UHD CMOS sensor for shooting high-quality 4K video at 60 FPS. Adjustable to numerous other resolutions and frame rates.
Simple Network Discovery: Easily discover and connect to a network.
Built-in Tally Light: Indicates if the camera is live or in preview mode.
| General Information | |
| Manufacturer | PTZOptics |
| Manufacturer Part Number | PT20X-4K-GY-G3 |
| Manufacturer Website Address | http://www.ptzoptics.com |
| Brand Name | PTZOptics |
| Product Line | MOVE |
| Product Model | PT20X-4K-GY-G3 |
| Product Name | Move Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| Recording Formats | 4K |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 30 ft |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Field of View | Horizontal & Vertical: H 3.5° ~ 60.7° | V 1.9° ~ 34.1° Display Field of View: 66.6 |
| Effective Camera Resolution | 8.4 Megapixel |
| Video | |
| Video Formats | YUY2 |
| Video Formats | MJPEG |
| Video Formats | H.265 |
| Video Formats | H.264 |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 60 fps |
| Analog Video Signal Format | SDI |
| Analog Video Signal Format | 3G-SDI |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 6.25 mm |
| Maximum Focal Length | 125 mm |
| Lens Included | Yes |
| Minimum Aperture | f/3.95 |
| Maximum Aperture | f/1.58 |
| Optical Zoom | 20x |
| Exposure | |
| Shortest Shutter Speed | 1/10000 Second |
| Longest Shutter Speed | 1/30 Second |
| PTZ Modes | Preset Point |
| Network & Communication | |
| Connectivity Technology | Wired |
| Ethernet Technology | Gigabit Ethernet |
| Protocols | VISCA |
| Protocols | PELCO-D |
| Protocols | PELCO-P |
| Remote Management | Yes |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | PoE |
| Power Source Type | PoE+ |
| Power Source Type | DC |
| Physical Characteristics | |
| Color Family | Gray |
| Product Color | Gray |
| Product Material | Plastic |
| Product Material | Aluminum |
| Height | 7.9" |
| Width | 5.6" |
| Depth | 6.7" |
| Weight (Approximate) | 3.25 lb |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Miscellaneous | |
| Features | Auto Tracking |
| Features | White Balance |
| Features | Built-in Tally Light |
| Features | Live View |
| Features | PTZ |
| Features | Mirror |
| Features | Wide Dynamic Range |
| Features | 3D Noise Reduction |
| Indoor/Outdoor | Indoor |
| Package Contents |
|
| Warranty | |
| Limited Warranty | 5 Year |
