SHUTTLE
SHUTTLE XPC XH510G2 BAREBONE PC H510 CHIPSET NO CPU/RAM/HDD/SSD/OS
Mfg Part Number: XH510G2 , Item #: 4772051
Image may not reflect the actual item.
Price: $511.60
+ Free Shipping
Quantity:
More to Come
Last Updated: Sep 30, 2025
No Sales Tax except these states
, PO and Wire.
FLEXIBLE 4.7-LITRE PC WITH PCIE SLOT
The Shuttle XPC slim Barebone XH510G2 is a 4.7-litre PC with two slots for PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.
The Shuttle XPC slim Barebone XH510G2 is a 4.7-litre PC with two slots for PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.
Main Specification
| General Information | |
| Manufacturer | Shuttle, Inc |
| Manufacturer Part Number | XH510G2 |
| Manufacturer Website Address | http://www.us.shuttle.com |
| Brand Name | Shuttle |
| Product Line | XPC slim |
| Product Model | XH510G2 |
| Product Name | XPC slim XH510G2 Barebone System |
| Product Type | Barebone System |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Socket | Socket LGA-1200 |
| Processor Supported | Core i7 |
| Processor Supported | Celeron |
| Processor Supported | Core i9 |
| Processor Supported | Core i3 |
| Processor Supported | Core i5 |
| Processor Supported | Pentium Gold |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | H510 Express |
| Memory | |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Total Number of Memory Slots | 2 |
| Storage | |
| Supported Storage Drive Interfaces | Serial ATA III |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 1 |
| Total Number of Expansion Slots | 2 |
| Number of PCI Express x16 Slots | 1 |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 8 |
| Number of USB 2.0 Ports | 4 |
| Number of USB 3.2 Gen 1 Ports | 4 |
| Operating System | |
| Operating System Supported | Windows 11 x64 |
| Operating System Supported | Linux |
| Operating System Supported | Windows 10 x64 |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Maximum Power Supply Wattage | 180 W |
| Physical Characteristics | |
| Height | 3.7" |
| Width | 7.9" |
| Depth | 9.8" |
| Weight (Approximate) | 6.57 lb |
| Miscellaneous | |
| Application/Usage | Business |
| Energy Star | Yes |
