ATEN VE2812PR HDMI HDBASET RECEIVER W/AUDIO DE-EMBEDDING AND POH

Featuring powerful Class A HDBaseT technology, the VE2812PR is a receiver for 4K HDMI video, audio, and control signals over a distance of up to 100 m via a Cat 5e / 6 / 6a or ATEN 2L-2910 Cat 6 cable. HDMI signal transmission extends further up to 150 m @ 1080p when the HDBaseT Long Reach Mode is enabled.

Designed to optimize flexibility, the VE2812PR ships with 2-way PoH capability, either allowing a PoH PD-enabled Tx (VE2812AT series is recommended) to be remotely powered by the locally powered VE2812PR, or enabling power distribution along the cable from a PoH PSE-enabled Tx (VE1812T is recommended) to the VE2812PR. Speaking of VE2812PR's audio de-embedding, audio signal can be extracted from the incoming HDMI source and then transmitted through Coaxial or Stereo output to external audio distribution systems. The VE2812PR gives users the extra convenience when it comes to extending control and communication signals via the built-in RS-232 and bi-directional IR ports. Plus, it is HDCP 2.2 compliant and supports HDMI specification features, such as 4K2K, 3D, Deep Color, and CEC for reliable transmission of high-quality uncompressed HDMI content.

With all highlights packed in a compact enclosure, the VE2812PR assures easy and discreet installation, keeping the presentation space tidy. It is ideal for small / mid-sized areas where 4K HDMI and control signal transmission over a long distance is required, such as boardrooms, lecture halls, and digital signage applications.

General Information
Manufacturer	ATEN Technology, Inc
Manufacturer Part Number	VE2812PR
Manufacturer Website Address	http://www.aten.com/us/en/
Brand Name	ATEN
Product Name	VE2812PR HDMI HDBaseT Receiver with Audio De-Embedding / Bi-directional PoH
Product Type	Video Extender Receiver
Technical Information
Connectivity Technology	Wired
Number of Output Devices Supported	1
Maximum Operating Distance	492.13 ft
Video
Graphics Modes	4K
Supported Video Modes	2160p
Maximum Video Resolution	4096 x 2160
Interfaces/Ports
Network (RJ-45)	Yes
HDMI Out	Yes
Number of Network (RJ-45) Ports	1
Number of HDMI Outputs	1
Media & Performance
Media Type Supported	Twisted Pair
Twisted Pair Cable Standard	Category 6a
Physical Characteristics
Color Family	Gray
Product Color	Gray
Receiver Height	1.18"
Receiver Width	4.84"
Receiver Depth	5.72"
Form Factor	Rack-mountable
Receiver Weight (Approximate)	1.10 lb
Miscellaneous
Package Contents	1 x VE2812PR HDMI HDBaseT Receiver with Audio De-Embedding / Bi-directional PoH 1 x RS-232 Terminal Block 1 x Foot Pad Set (4 pcs) 1 x Power Adapter 1 x User Instructions
Warranty
Limited Warranty	3 Year
