The EVGA GeForce RTX 3080 delivers the unprecedented performance that gamers crave for 4K resolution gaming, powered by the NVIDIA Ampere architecture. It's built with enhanced RT Cores and Tensor Cores, new streaming multiprocessors, and superfast G6X memory for an amazing gaming experience. Combined with the next generation of design, cooling, and overclocking with EVGA Precision X1, the EVGA GeForce RTX 3080 Series presents a new definition in ultimate performance.
General Information | |
Manufacturer | EVGA Corporation |
Manufacturer Part Number | 10G-P5-3898-KL |
Manufacturer Website Address | http://www.evga.com |
Brand Name | EVGA |
Product Line | FTW3 Ultra Hybrid Gaming |
Product Name | FTW3 Ultra Hybrid Gaming Graphic Card |
Product Type | Graphic Card |
Technical Information | |
API Supported | VulkanRT |
API Supported | OpenGL 4.6 |
API Supported | DirectX 12 Ultimate |
Features | AV1 Encode/Decode |
Features | Dual-fan Cooler |
Features | VR Ready |
Maximum Digital Display Resolution | 7680 x 4320 |
CUDA Cores | 8704 |
Processor & Chipset | |
Chipset Manufacturer | NVIDIA |
Chipset Line | GeForce |
Chipset Series | RTX |
Chipset Model | RTX 3080 |
GPU Boost Clock | 1.80 GHz |
Memory | |
Standard Memory | 10 GB |
Memory Technology | GDDR6X |
Bus Width | 320 bit |
Maximum Memory Bandwidth | 760 GB/s |
Interfaces/Ports | |
Host Interface | PCI Express 4.0 x16 |
DisplayPort | Yes |
Number of DisplayPort Outputs | 3 |
HDMI | Yes |
Number of HDMI Outputs | 1 |
Power Description | |
Power Supply Wattage | 750 W |
Power Connector | 3x 8-pin |
Physical Characteristics | |
Slot Space Required | Dual |
Form Factor | Plug-in Card |
Cooler Type | Fan Cooler |
Height | 5.4" |
Length | 11.4" |
Miscellaneous | |
Platform Supported | PC |
Warranty | |
Limited Warranty | 3 Year |
