The Zyxel NWA220AX-6E features 6 spatial streams (4x4 in 6 GHz/5 GHz selectable, 2x2 in 2.4 GHz) with a maximum data rate of 5.4 Gbps. This dual-radio access point includes a BandFlex radio that can be configured to support either 5 GHz or 6 GHz, making it a cost-effective option for expanding your existing 5 GHz coverage while also future-proofing your network with 6 GHz support.
The NWA220AX-6E brings the benefits of WiFi 6 capabilities, including OFDMA, MU-MIMO, and BSS Coloring, into the newly available, interference-free 6 GHz band. This new band more than doubles WiFi capacity, offering multi-gigabit speeds and low-latency connections.
The interference-free 6 GHz band addresses the growing demand for bandwidth in today's networks, making it ideal for high-density WiFi environments and emerging technology connectivity. To fully unlock the potential of this new band, Zyxel's 6E Boost uses high-gain 4x4 streams in the 6 GHz band to improve transmit beamforming and receive MIMO, extending its range and ensuring optimal performance.
The NWA220AX-6E is perfect for high-density environments such as transport hubs, exhibition halls, schools, offices, hotels, restaurants, or any organization that needs to support a large number of devices. It provides optimal, premium WiFi service for users, ensuring top performance every time they connect.
| General Information | |
| Manufacturer | ZYXEL Communications Corp. |
| Manufacturer Part Number | NWA220AX-6E |
| Manufacturer Website Address | http://www.us.zyxel.com |
| Brand Name | ZYXEL |
| Product Model | NWA220AX-6E |
| Product Name | AXE5400 WiFi 6E Dual-Radio Access Point |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Network Band | Tri Band |
| Frequency Band | 5 GHz |
| Frequency Band | 6 GHz |
| Frequency Band | 2.40 GHz |
| Wireless Transmission Speed | 5.40 Gbit/s |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3 |
| Encryption Standard | WPA |
| Encryption Standard | WEP |
| Encryption Standard | WPA2 |
| Interfaces/Ports | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| PoE PD Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6E |
| Communication Protocols | RADIUS |
| Communication Protocols | SNMP |
| Wireless Performance | AXE5400 |
| Physical Characteristics | |
| Form Factor | T-bar Mount |
| Form Factor | Plate Mountable |
| Antenna Form Factor | Internal |
| Height | 1.7" |
| Width | 7.1" |
| Depth | 7.1" |
| Weight (Approximate) | 1.43 lb |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | China |
