LENOVO 7Y77A00BWW 4U60 CHAS

Lenovo ThinkSystem DE4000H is a scalable, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for medium to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE4000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications.

ThinkSystem DE4000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF), 12 large form-factor (3.5-inch LFF) drives (2U12 LFF), or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 8 GB or 32 GB memory for a system total of 16 GB or 64 GB. Host interface cards provide 12 Gb SAS, 10/25 Gb iSCSI, or 8/16/32 Gb FC connections.

The ThinkSystem DE4000H Storage Array scales up to 192 drives with the attachment of Lenovo ThinkSystem DE120S 2U12, DE240S 2U24 SFF, and DE600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 10 K rpm SAS and 7.2 K rpm NL SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).

General Information
Manufacturer	Lenovo Group Limited
Manufacturer Part Number	7Y77A00BWW
Manufacturer Website Address	http://www.lenovo.com/us/en/
Brand Name	Lenovo
Product Line	ThinkSystem
Product Series	DE
Product Model	DE4000H
Product Name	ThinkSystem DE4000H DAS/SAN Storage System
Product Type	DAS/SAN Storage System
Storage
Number of Hard Drives Supported	60
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	60
Number of Solid State Drive Installed	No
Flash Memory Capacity	64 GB
Network & Communication
Ethernet Technology	Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays	60
Number of 3.5" Bays	60
Controllers
Number of Controllers	2
Controller Type	Serial Attached SCSI (SAS)
RAID Supported	Yes
RAID Levels	0, 1, 3, 5, 6, 10
Interfaces/Ports
Total Number of USB Ports	2
Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	2
Fibre Channel	Yes
Management & Protocols
Protocols	SNMP
Protocols	SSH
Protocols	SMI-S
Protocols	LDAP
Protocols	SSL
Protocols	FCP
Power Description
Number of Power Supplies Installed	2
Plug/Connector Type	C19 to IEC 320-C20
Maximum Power Supply Wattage	2325 W
Redundant Power Supply	Yes
Physical Characteristics
Height	6.9"
Width	17.7"
Depth	36.3"
Form Factor	Rack-mountable
Rack Height	4U
Miscellaneous
Package Contents	ThinkSystem DE4000H DAS/SAN Storage System Rack Mount Kit 2 m USB Cable (USB Type A to Micro-USB) Quick Installation Guide Electronic Publications Flyer 2 x Power Cables
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty	3 Year
Additional Warranty Information	Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
