Panduit
Panduit U02N11L SMARTZONE UPS 1.5KVA 2U 120VSINGLE PHASE LIT-ION PPWINC
Mfg Part Number: U02N11L , Item #: 4611628
Image may not reflect the actual item.
Price: $2,053.84
Quantity:
More to Come
Last Updated: Jun 18, 2025
No Sales Tax except these states
, PO and Wire.
The Panduit®SmartZone™Intelligent Rack UPS with compact, high capacity, and long life Lithium Ion battery, 1-3kVA single phase 120 V Line-Interactive unit and 230 V unit with pure Online Double Conversion system that delivers highly efficient and reliable power protection and backup power for your computer IT equipment. With excellent electrical performance, enhanced intelligent monitoring and network functions and complying with EMC and safety standards to meet the continually growing power demands of Data Center, Enterprise and Edge IT equipment.
Main Specification
| General Information | |
| Manufacturer | PANDUIT CORP |
| Manufacturer Part Number | U02N11L |
| Manufacturer Website Address | http://www.panduit.com |
| Brand Name | Panduit |
| Product Model | U02N11L |
| Product Name | SmartZone UPS 1-3kVA Lithium Ion |
| Product Type | Line-interactive UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 6 x NEMA 5-15R |
| Overload Protection | Yes |
| Transfer Time | 6 ms |
| Phase | Single Phase |
| Application/Usage | Edge Computing |
| Application/Usage | IT Equipment |
| Application/Usage | Computer |
| Application/Usage | Data Center |
| Application/Usage | Enterprise |
| Power Description | |
| Load Capacity (VA) | 1500 VA |
| Load Capacity (Watt) | 1350 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 100 V AC - 125 V AC |
| Output Voltage | 120 V AC |
| Output Voltage | 115 V AC |
| Output Voltage | 125 V AC |
| Output Voltage | 100 V AC |
| Output Voltage | 110 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Controls/Indicators | |
| Status Indicators | LCD Display |
| Interfaces/Ports | |
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| DC System Voltage | 48 V DC |
| Battery Characteristics | Hot-swappable |
| Battery Chemistry | Lithium-Ion (LiFePO4) |
| Backup/Run Time (Full Load) | 7.50 Minute |
| Backup/Run Time (Half Load) | 19 Minute |
| Typical Battery Recharge Time | 4 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | -13°F (-25°C) - 131°F (55°C) |
| Maximum Operating Elevation | 9842.52 ft |
| Sound Emission | 55 dB |
| Thermal Dissipation | 41.62 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 3.4" |
| Width | 17.3" |
| Depth | 18.1" |
| Rack Height | 2U |
| Form Factor | Tower/Rack Convertible |
| Form Factor | Compact |
| Weight (Approximate) | 37.70 lb |
| Miscellaneous | |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 5 Year |
WARNING:: The plastic used in cable products can expose you to lead and lead components,
chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
