Lenovo ThinkSystem SR630 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 server is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
General Information | |
Manufacturer | Lenovo Group Limited |
Manufacturer Part Number | 7X02T0LA00 |
Manufacturer Website Address | http://www.lenovo.com/us/en/ |
Brand Name | Lenovo |
Product Line | ThinkSystem |
Product Series | SR630 |
Product Model | 7X02T0LA00 |
Product Name | ThinkSystem SR630 7X02T0LA00 Server |
Product Type | Server |
Processor | |
Number of Processors Supported | 2 |
Chipset | |
Chipset Manufacturer | Intel |
Chipset Model | C624 |
Memory | |
Memory Technology | TruDDR4 |
Memory Clock Speed | 2.93 GHz |
Error Checking | ECC |
Total Number of Memory Slots | 24.0 |
Intel Optane Memory Ready | Yes |
Signal Processing | Registered (Buffered) |
Storage | |
Optical Drive Type | No |
Controllers | |
Controller Type | 12Gb/s SAS |
RAID Supported | Yes |
I/O Expansions | |
Hot Swappable Bays | Yes |
PCI Express x8 (Gen 3.x) Slots | 1 |
PCI Express Details | PCIe 3.0 x8 (dedicated to an internal storage controller) |
Display & Graphics | |
Graphics Controller Model | G200e |
Graphics Memory Capacity | 16 MB |
Network & Communication | |
Ethernet Technology | 10 Gigabit Ethernet |
Ethernet Technology | Gigabit Ethernet |
Interfaces/Ports | |
Total Number of USB Ports | 4 |
Number of USB 2.0 Ports | 1 |
Number of USB 3.0 Ports | 3 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 1 |
VGA | Yes |
Remote Management | Yes |
Remote Management Controller | XClarity Controller (XCC) |
Operating System | |
Operating System Supported | Windows Server |
Operating System Supported | Red Hat Enterprise Linux |
Operating System Supported | SuSE Linux Enterprise Server |
Power Description | |
Input Voltage | 120 V AC |
Input Voltage | 230 V AC |
Number of Power Supplies Supported | 2 |
Plug/Connector Type | C13/C14 |
Physical Characteristics | |
Form Factor | Rack |
Rack Height | 1U |
Height | 1.7" |
Width | 17.1" |
Depth | 30.1" |
Weight (Approximate) | 57.32 lb |
Miscellaneous | |
Package Contents | |
Security Features | |
Energy Star | Yes |
Environmentally Friendly | Yes |
Energy Efficiency Certification | ENERGY STAR 3.0 |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
