BLACK BOX
BLACK BOX USBC2000-4KDUAL USB-C DOCKING STATION - 4K DUAL
Mfg Part Number: USBC2000-4KDUAL , Item #: 4490155
, PO and Wire.
The Black Box USB-C Docking Station - 4K, Dual (USBC2000-4KDUAL) with PD/Alt/KM sharing for laptops merges cutting-edge technology and high-quality hardware with innovative design elements.
Connect two 4K DisplayPort monitors and one 4K HDMI monitor, while sharing one keyboard and mouse with two MacBook Pro or Windows laptop hosts with this multi-port adapter.
The docking station includes two USB C host ports and cables, one audio-in and one audio-out port for the switched host, one 4K HDMI and two 4K DisplayPort video ports, a LAN port, two super-speed USB 3.2 Gen2x1 Type A ports, and one super-speed USB 3.2 Gen2x1 Type C port for peripherals, one keyboard port, and one mouse port.
Supports Dual Host and Screen-Sharing
With the KVM sharing features add on, the docking station allows the user to switch the display (HDMI/DP/DP) monitors/USB-peripherals via multi-switch mode with a dual host (desktop/laptop/tablet) at the same time.
With the KM sharing feature, the USBC200-4KDUAL enables the user to move the mouse/touchpad cursor between different hosts.
Super-Fast and Backward-Compatible
The USB-C docking station supports USB 3.2 Gen2x1 (10 Gbps) data transmission. Even better, it's backward-compatible with USB 3.0 and 2.0, so you aren't limited by legacy hardware.
Includes USB Host Charging Ports
USB-C host 1 and host 2 ports can charge device 1 and device 2 at the same time. Each device draws 100 W power for a total of 200 W maximum for both host ports.
| General Information | |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | USBC2000-4KDUAL |
| Manufacturer Website Address | http://www.blackbox.com |
| Brand Name | Black Box |
| Product Name | USB-C Docking Station - 4K, Dual |
| Product Type | Docking Station |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Displays Supported | 2 |
| Supported Resolutions | 4096 x 2160 |
| Screen Mode Supported | 4K |
| Device Supported | Notebook/Tablet/Monitor/Desktop PC/Keyboard/Mouse |
| Network & Communication | |
| Ethernet Technology | Ethernet |
| Interfaces/Ports | |
| Host Interface | USB 3.2 (Gen 2) Type C |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Type-A Ports | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | 3 x USB 3.2 Gen 2 Type C Female |
| Number of USB Type-A Ports | 4 |
| USB Type-A | Yes |
| Number of RJ-45 Ports | 1 |
| Network (RJ-45) | Yes |
| Number of DisplayPorts | 2 |
| DisplayPort | Yes |
| DisplayPort Version | 1.4 |
| Headphone/Microphone Combo Port | Yes |
| Number of HDMI Ports | 1 |
| HDMI | Yes |
| Software | |
| Operating System Supported | Windows 8.1 |
| Operating System Supported | Windows 7 |
| Operating System Supported | Mac OS X 10.10 Yosemite |
| Operating System Supported | Windows 10 |
| Operating System Supported | Mac OS X 10.11 El Capitan |
| Operating System Supported | Mac OS X 10.12 Sierra |
| Power Description | |
| Maximum Power Supply Wattage | 230 W |
| Physical Characteristics | |
| Product Color | Black |
| Height | 3.50" |
| Width | 8.60" |
| Depth | 1.30" |
| Weight (Approximate) | 1.50 lb |
| Miscellaneous | |
| Package Contents |
|
| Kensington Security Slot | Yes |
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 1 Year |
