Contec Americas

Contec Americas COM-1C-LPE 1 CHANNEL RS-232C Serial I/O board Low Profile size for PCI Express

Mfg Part Number:  COM-1C-LPE
Image may not reflect the actual item.
Price: $272.01
Quantity:
Status: Active
No Sales Tax except these states
, PO and Wire.
Features :
  • Can be used a standard COM port in Windows or Linux environments
  • Utilizes high-speed PCI-Express x1 Bus
    		•




    Specifications :
  • Number of channels: 1
  • Interface: RS232C
  • Transfer method: Asynchronous serial transfer
  • Baud rate: 2 to 921,600bps - software selectable
         dependent upon environment
  • Data length: 5, 6, 7, 8bits
         1, 1.5, 2 stop bits
         Software selectable
  • Parity check: Even, odd, non-parity
         Software selectable
  • Controller chip: 162850 or equivalent
  • FIFO buffers: 128byte receive and 128byte transmit
  • Cabling distance: 15m (typ)
  • Interrupt requests: 1 level use
         all signals connect as a single interrupt
  • I/O address: Any 32byte boundary
  • Power consumption: 3.3VDC 300mA (max)
  • Operating temperature: 0 to 50°C
  • Operating humidity: 10 to 90% (no condensation)
  • Bus specification: PCI Express Specification Rev1.0a x1
  • Dimensions: 121.69 (l) x 67.90mm (h)
         4.79" (l) x 2.67" (h)
  • Interface connector: 9-pin d-sub DELC-J9PAF-20L9 - male
         (mfg by JAE)
    		•
