Asus SV RS700-E10-RS12U-WOCPU006Z 1U Xeon Scalable PCH C621A Brown Box
Mfg Part Number: RS700-E10-RS12U-WOCPU006Z , Item #: 4469923
Image may not reflect the actual item.
Price: $2,144.13
+ Free Shipping
Quantity:
More to Come
Last Updated: Aug 15, 2025
No Sales Tax except these states
, PO and Wire.
1U dual-socket server powered 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, one dual-slot GPU, 12 NVMe, four PCIe lots, one OPC 3.0, one M.2 and ASUS ASMB10-iKVM.
- Powered by dual-socket 3rd Gen Intel Scalable processors, with 32 DIMMs and support for a maximum TDP of up to 270 W per socket
- GPU-optimized design allows one dual-slot GPU for AI workloads
- Up to 12 all-flash NVMe drives on front panel to enable extensive storage and high-throughput performance
- Up to three PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options
- Flexible air- and liquid-cooling solution to achieve lower power-usage effectiveness (PUE) and optimized TCO for data centers
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- High power efficiency with redundant 1600 W or 1200 W 80 Plus® Titanium/Platinum power supplies
Main Specification
| General Information | |
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | RS700-E10-RS12U-WOCPU006Z |
| Manufacturer Website Address | http://usa.asus.com |
| Brand Name | Asus |
| Product Model | RS700-E10-RS12U |
| Product Name | RS700-E10-RS12U Barebone System |
| Product Type | Barebone System |
| Processor | |
| Number of Processors Supported | 2 |
| Processor Socket | Socket LGA-4189 |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Silver |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621A |
| Memory | |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Total Number of Memory Slots | 32 |
| Intel Optane Memory Ready | Yes |
| Storage | |
| Supported Storage Drive Interfaces | SAS |
| Supported Storage Drive Interfaces | Serial ATA III |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| Display & Graphics | |
| Graphics Controller Model | AST2600 |
| Graphics Memory Capacity | 64 MB |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 12 |
| Number of PCI Slots | 4 |
| Number of PCI Express x8 Slots | 1 |
| Number of PCI Express x16 Slots | 3 |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.1 Gen 1 Ports | 2 |
| Number of SATA Interfaces | 2 |
| Number of VGA Ports | 2 |
| Power Description | |
| Number of Power Supplies Installed | 2 |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 33.2" |
| Weight (Approximate) | 30.20 lb |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
