SIERRA 1104786 XR90 INCLUDES 1-YEAR AIRLINK PREMIUM

The supercharged AirLink XR90 is purpose-built for public safety and transit with available dual-5G cellular radios and dual independent 4x4 MIMO Wi-Fi 6 subsystems. The XR90 is the highest performing, most flexible router in the Sierra portfolio. It supports complete device-to-cloud security, reduces your total cost of ownership with AirLink® Management Service (ALMS) Out-of-Band management, and with the cartridged-based design, enables long-term expandability and upgradability.

A Fully Integrated Solution

The AirLink XR90 is a fully-supported, out-of-the-box solution complete with AirLink Premium for integrated device management, Advanced Mobility Reporting, 24/7 technical support and advanced device replacement. AirLink Connection Manager delivers complete VPN security while our AirLink Professional Services team maximizes your system performance and customer satisfaction.

Ideal Applications

Mobile mission critical applications in public safety, transit and field services. Delivers secure always-on Vehicle Area Networks (VANS) for:

• Buses/Transit
• Ambulance/EMS
• Law Enforcement
• Fire
• Utilities
• Private Networking

Benefits

• Designed for rugged mobile applications with Mil Standard aluminum die cast housing and adaptive power management
• Real-time connectivity with unmatched uplink and downlink speeds using Data Path Accelerated 5G, Wi-Fi 6 and 5 Gbps Ethernet technology
• "Always-on" connectivity using available dual cellular and dual Wi-Fi radios, and automatic failover using AirLink Cognitive Wireless
• Simplified set up and usability with AirLink OS and upgraded ALMS
• AirLink Premium with ALMS Out-of-Band Management provides zero-touch set up and reduced service calls advanced device replacement

General Information
Manufacturer	Sierra Wireless
Manufacturer Part Number	1104786
Manufacturer Website Address	http://www.sierrawireless.com
Brand Name	Sierra Wireless
Product Line	AirLink
Product Model	XR90
Product Name	AirLink XR90 Modem/Wireless Router
Product Type	Modem/Wireless Router
Technical Information
Wi-Fi Generation	Wi-Fi 6
Network Band	Dual Band
Wireless Specifications
Broadband Transmission Technology	Cellular
Broadband Transmission Technology	Ethernet
Wireless LAN Standard	IEEE 802.11ax
ISM Band	Yes
UNII Band	Yes
ISM Maximum Frequency	2.40 GHz
UNII Maximum Frequency	5 GHz
Cellular Generation	5G
Cellular Data Connectivity Technology	LTE
Cellular Data Connectivity Technology	HSDPA+
Total Wireless Transmission Speed	307.20 MB/s
Encryption Standard	AES (128-bit)
Encryption Standard	SHA-512
Encryption Standard	SHA-384
Encryption Standard	AES (192-bit)
Encryption Standard	WPA3-ENT
Encryption Standard	AES (256-bit)
Encryption Standard	WPA3-Personal
Encryption Standard	WPA2-ENT
Encryption Standard	WPA2-PSK
Encryption Standard	SHA-256
Firewall Type	NAT
Interfaces/Ports
Number of Network (RJ-45) Ports	4
USB	Yes
Network & Communication
Ethernet Technology	5 Gigabit Ethernet
VPN Supported	Yes
Multi-SIM Supported	Yes
Number of SIM Card Supported	2
Physical Characteristics
Height	2.1"
Width	8.7"
Depth	6.7"
Weight (Approximate)	4.54 lb
Miscellaneous
Package Contents	AirLink XR90 Modem/Wireless Router DC Power Cable LPWA Antenna Quick Start Guide AirLink Premium Leaflet
Environmentally Friendly	Yes
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Warranty
Limited Warranty	1 Year
Additional Warranty Information	1 year standard warranty with up to 5 years extended warranty with current AirLink Premium subscription. Unrestricted critical firmware updates.
