STARTECH TB3CDK2DH TB3/USB-C DOCK - DUAL DP/HDMI 96W PD 5X USB HUB

A high-performance Thunderbolt™ Certified docking station with USB Type-C® compatibility featuring dual monitor 4K 60Hz DSC support from either dual DisplayPort or dual HDMI 2.0 video outputs, 96W Power Delivery (100W peak power), 5x USB 3.2 Hub with 2x BC 1.2 fast charging ports, Gigabit Ethernet (PXE Boot/Wake-on-LAN) & headset ports.

Flexible Dual Display Outputs

This universal docking station features both dual DisplayPort 1.4 (Single 8K30 on HBR3 host) and dual HDMI video outputs that can be configured in three different ways:

DisplayPort + DisplayPort HDMI + HDMI DisplayPort + HDMI

Resolutions and video outputs are host-dependent.

Thunderbolt 3 or 4 Laptop

Single Monitor

Dual Monitors Intel Laptops with 11th Gen or Later

8K 30Hz / 5K 60Hz / 4K 60Hz 4K 60Hz Intel Laptops with 10th Gen or Earlier

5K 60Hz / 4K 60Hz 4K 60Hz Apple M1 & M2 Pro/Max MacBooks

5K 60Hz / 4K 60Hz 4K 60Hz Apple M1 & M2 MacBooks

5K 60Hz / 4K 60Hz Mirrored Display Only Intel Based MacBook's with Thunderbolt 3

5K 60Hz / 4K 60Hz 4K 60Hz

USB-C Laptop (No Thunderbolt)

Single Monitor

Dual Monitors Laptops with Intel 10th Gen or Later (Requires DP 1.4 Alt Mode)

4K 60Hz 4K 30Hz Laptops with DP 1.2 Alt Mode

4K 30Hz 1080p 60Hz

More Downstream USB Ports

Featuring an integrated USB 3.2 hub, this docking station has 5 downstream USB ports:

Front Facing:

• 1x USB 3.2 Gen 2 Type-C (10 Gbps) with 15W (3A, 5V) Charging
• 1x USB 3.2 Gen 2 Type-A (10 Gbps) with B.C. 1.2 Fast-Charging

Back Facing:

• 2x USB 3.2 Gen 1 Type-A (5 Gbps)
• 1x USB 3.2 Gen 2 Type-C (10 Gbps)

Easy to Set Up & Manage

This universal Thunderbolt / USB-C Dock has an automatic driver setup and includes a longer 0.8 meter (2.6 ft) Thunderbolt host cable, front-facing TB3/USB-C host port, front-facing LED indicator, mounting holes for the optional bracket, k-slot for security lock & MAC address changer utility.

Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application

Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

• Advanced Windows Layout Utility: To setup and save custom windows layouts.

• Mac Address Pass-Through Utility: To improve network security.

• USB Event Monitoring Utility: To track and log connected USB devices

• Wi-Fi Auto Switch Utility: Enabling users to quickly access faster network speeds via wired LAN.

For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-Tools

More from the Manufacturer

General Information
Manufacturer	StarTech.com
Manufacturer Part Number	TB3CDK2DH
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Name	Docking station
Packaged Quantity	1 Each
Product Type	Docking Station
Technical Information
Connectivity Technology	Wired
Device Supported	Monitor/Notebook/Workstation
Number of Displays Supported	2
Screen Mode Supported	8K
Supported Resolutions	4096 x 2160
Supported Resolutions	7680 x 4320
Supported Resolutions	5120 x 2880
Network & Communication
Ethernet Technology	Gigabit Ethernet
Interfaces/Ports
Host Interface	Thunderbolt
Audio Line Out	Yes
USB Type-A	Yes
USB Type-C	No
USB Type-C Detail	2 x USB-C (USB 3.1 Gen 2)
Network (RJ-45)	Yes
DisplayPort	Yes
HDMI	Yes
Thunderbolt	No
Software
Operating System Supported	Mac OS X 10.14 Mojave
Operating System Supported	Windows 11
Operating System Supported	Windows 8
Operating System Supported	Ubuntu 18.04
Operating System Supported	Ubuntu 20.04
Operating System Supported	Mac OS X 12.0 Monterey
Operating System Supported	Mac OS X 13.0 Ventura
Operating System Supported	Windows 10
Operating System Supported	Mac OS X 11.0 Big Sur
Operating System Supported	Mac OS X 10.15 Catalina
Operating System Supported	macOS 14
Power Description
Maximum Power Supply Wattage	96 W
Physical Characteristics
Color Family	Dual Color
Product Color	Black
Product Color	Space Gray
Height	1.20"
Width	8.70"
Length	3.1"
Weight (Approximate)	8.80 oz
Miscellaneous
Package Contents	Docking Station Universal Power Adapter Power Cords (NA/JP, ANZ) Thunderbolt 3 Host Cable (80 cm) User Manual
Kensington Security Slot	Yes
Compatibility	HP Notebooks Lenovo ThinkPad Notebooks Dell XPS Notebooks Apple Products: MacBook Air MacBook Pro
Brand Compatibility	HP
Brand Compatibility	Lenovo
Brand Compatibility	Apple
Brand Compatibility	Dell
Country of Origin	Malaysia
Warranty
Limited Warranty	3 Year
