ALLIED TELESIS AT-TQ6602-01 IEEE 802.11AX WIRELESS ACCESS POINT WITH DUAL BAND RADIOS AND EMBEDDED ANTENNA.

The innovative TQ6602 is the world's first Wi-Fi 6 AP to support multichannel, single-channel1 (Channel Blanket) and hybrid operation (the simultaneous use of multi-channel and Channel Blanket). This powerful solution combines maximum performance and seamless roaming to enable the most flexible wireless networks available, and the best possible user experience.

The TQ6602 has one 2.4GHz and one 5GHz Wi-Fi6 (802.11ax) radio, and supports Multi-User Multiple Input and Multiple Output (MU-MIMO), allowing multiple clients to send and receive data at the same time, substantially increasing throughput. A comprehensive feature-set provides a superior solution for Enterprise businesses.

The TQ6602 in standalone mode can be managed using its intuitive webbased interface. For medium and larger installations, Autonomous Wave Control (AWC) provides centralized management, and regularly analyses the wireless network, automatically optimizing AP settings to reduce interference and minimize coverage gaps-all with no user intervention. AWC wireless management is available on our Vista Manager EX network management platform, and from Vista Manager mini running on a number of switch and firewall products.

Flexible deployment options include desktop use, and wall or ceiling mounting. Power can be supplied by Power over Ethernet, or by an optional AC power adapter.

General Information
Manufacturer	Allied Telesis, Inc
Manufacturer Part Number	AT-TQ6602-01
Manufacturer Website Address	http://www.alliedtelesis.com
Brand Name	Allied Telesis
Product Model	TQ6602
Product Name	TQ6602 Hybrid Wi-Fi 6 (802.11ax) Wireless Access Point
Product Type	Wireless Access Point
Technical Information
Wireless LAN Standard	802.11ax
Network Band	Dual Band
Frequency Band	5 GHz
Frequency Band	2.40 GHz
Wireless Transmission Speed	2.35 Gbit/s
MIMO Technology	Yes
Data Encryption	Yes
Encryption Standard	64-bit WEP
Encryption Standard	TKIP
Encryption Standard	128-bit WEP
Encryption Standard	WPA3-PSK
Encryption Standard	WPA2-PSK
Encryption Standard	WPA3-ENT
Encryption Standard	WPA2-ENT
Encryption Standard	WPA-PSK
Encryption Standard	AES-CCMP
Encryption Standard	WPA-ENT
Interfaces/Ports
Ethernet Technology	5 Gigabit Ethernet
Number of Network (RJ-45) Ports	1
PoE PD Port	Yes
Power Description
Power Consumption	20 W
Physical Characteristics
Form Factor	Ceiling Mountable
Form Factor	Desktop
Form Factor	Wall Mountable
Antenna Form Factor	Internal
Height	2"
Width	8.1"
Depth	8.9"
Weight (Approximate)	3.53 lb
Miscellaneous
Country of Origin	China
