HANWHA TECHWIN
HANWHA TECHWIN SCB-6005 WISENET HD+ 2MP, FULL HD(1080P) 30FPS, 1/2.8IN 2M CMOS, 60DB DWDR, RS485 /COAXIA
Mfg Part Number: SCB-6005 , Item #: 4426933
Image may not reflect the actual item.
Price: $108.00
+ Free Shipping
Quantity:
More to Come
Last Updated: Jun 24, 2025
No Sales Tax except these states
, PO and Wire.
WiseNet HD+ box cameras allow users to upgrade their surveillance systems to HD using legacy coax cabling without the costly process of ripping and replacing coax with Ethernet cabling. The new WiseNet HD+ cameras offer a variety of high-performance features including Day/Night operation, motion detection, defog, IR illuminators and more depending on model. Setup functions are easily controlled by OSD with the built-in joystick or control over coaxial cable with WiseNet HD+ DVRs. Low power consumption, compact form factors, and transmission up to 1,640 feet further enhance the lineup. Lens optional.
Main Specification
| General Information | |
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | SCB-6005 |
| Manufacturer Website Address | http://www.hanwha.com |
| Brand Name | Wisenet |
| Product Series | HD+ |
| Product Model | SCB-6005 |
| Product Name | 1080p Full HD Analog Box Camera |
| Product Type | Surveillance Camera |
| Technical Information | |
| Recording Formats | Full HD |
| HD Recording | Yes |
| Night Vision Type | Color |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 30 fps |
| Analog Video Signal Format | CVBS |
| Analog Video Signal Format | AHD |
| Lens | |
| Lens Mount Type | C/CS-mount |
| Maximum Aperture | f/1.2 |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 1 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | No |
| Power Description | |
| Input Voltage | 24 V AC |
| Input Voltage | 12 V DC |
| Physical Characteristics | |
| Form Factor | Box |
| Color Family | Dual Color |
| Product Color | Black |
| Product Color | Ivory |
| Height | 2.3" |
| Width | 2.7" |
| Depth | 3.6" |
| Weight (Approximate) | 6.56 oz |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Maximum Operating Humidity | 90% |
| Miscellaneous | |
| Features | Automatic White Balance |
| Features | Motion Detection |
| Features | Built-in Joystick |
| Features | Day/Night |
| Features | Privacy Masking |
| Features | Highlight Compensation (HLC) |
| Features | Digital Noise Reduction |
| Features | Built-in Infrared Illuminator |
| Features | Digital Wide Dynamic Range (D-WDR) |
| Features | Back Light Compensation (BLC) |
| Features | Gain Control |
| Features | Defog |
| Indoor/Outdoor | Indoor/Outdoor |
