Supermicro SV SYS-740P-TR 4U Xeon Socket P+ LGA4189 4TB DDR4 8x3.5HS BrownBox

Mfg Part Number:  SYS-740P-TR
Image may not reflect the actual item.
Price: $2,356.53
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Nov 11, 2025
No Sales Tax except these states
, PO and Wire.

GPU Systems

Best GPU Servers for Modern Data Centers. The Most Comprehensive AI Systems Featuring the Latest NVIDIA Ampere based GPU Platforms

Highly Optimized GPU-to-GPU Interconnect Architectures

Choose from a broad range of Supermicro GPU optimized SuperServers supporting NVIDIA® NVLink™, Dual-Root Complex or Single Root Complex PCI-E interconnect architectures for target applications and the best AI / Deep Learning performance.

Accelerated Deployment and Peace of Mind

Risk-free investments for guaranteed quality and system performance with our Qualified GPU and Supermicro Server Platform List.

Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number SYS-740P-TR
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line SuperServer
Product Model 740P-TR
Product Name SuperServer SYS-740P-TR (Black)
Product Type Server Barebone System
Processor
Number of Processors Supported 2
Processor Socket Socket LGA-4189
Processor Supported Xeon Platinum
Processor Supported Xeon Gold
Processor Supported Xeon Silver
Processor Supported Xeon Bronze
64-bit Processing Yes
Chipset
Chipset Manufacturer Intel
Chipset Model C621A
Memory
Maximum Memory Supported 4 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Total Number of Memory Slots 18
Intel Optane Memory Ready Yes
Storage
Supported Storage Drive Interfaces Serial ATA III
Supported Storage Drive Interfaces M.2
Controllers
Controller Type Serial ATA/600
Display & Graphics
Graphics Controller Model AST2600
Network & Communication
Ethernet Technology Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 8
Number of 3.5" Bays 8
Total Number of Expansion Slots 6
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 4
Interfaces/Ports
Total Number of USB Ports 6
Number of USB 3.0 Ports 4
Number of VGA Ports 1
Power Description
Input Voltage 230 V AC
Input Voltage 120 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1200 W
Physical Characteristics
Color Family Black
Product Color Black
Form Factor Tower
Rack Height 4U
Height 17.8"
Width 7"
Depth 25.5"
Weight (Approximate) 56.44 lb
Miscellaneous
Package Contents
  • SuperServer SYS-740P-TR (Black)
  • 1 x Super X12DPi-N6 Motherboard
  • 1 x Tower/4U Chassis
  • 1 x 8-port 4U/Tower 3.5-inch SAS3/SAS2/SATA3 12Gbps backplane for SC743/SC745 chassis
  • 2 x Internal Mini-SAS to Mini-SAS HD 50cm w/ SB, 30AWG
  • 2 x Internal Mini-SAS to Mini-SAS HD 50cm w/ SB, 30AWG
  • 1 x STD I/O shield for X9 socket R server MB with Gasket.
  • 1 x SYS-740P-TR(T) Quick Reference Guide
  • 2 x 2U Passive CPU Heat Sink for X12 Generation Intel Whitley and Cedar Island Platforms
  • 2 x 1U, Redundancy, Titanium, Input: 100-127Vac, 200-240Vac
  • 1 x POWER DISTRIBUTOR FOR SC747 W/ GRAPHIC OUTPUT FEATURE
  • 1 x CBL,FRONT CNTL,16 TO 16 PIN,Ribbon,50CM
  • 2 x US POWER CORD 16AWG, PB FREE
  • 3 x 4 TO 4 PIN FAN POWER CABLE, 210MM
  • 1 x USB3.0 Internal Cable-80cm (19pin Female to 19pin Female)
  • 2 x 80x80x38 mm, 9.4K RPM, Hot-swappable Rear Exhaust Fan for X11 Purley Platform Newly Enabled 4U Chassis
  • 3 x 80x80x38 mm, 9.4K RPM, Hot-swappable Middle Cooling Fan for X11 Purley Platform Newly Enabled 4U Chassis
  • 1 x Plastic feet (4 pcs set) for 4U tower chassis, black color
  • 1 x SC745 Intel DP X9, X8 PC air shroud 1368x13/12x13MB
Warranty
Limited Warranty 3 Year
