Supermicro SV SSG-540P-E1CTR36H 4U Xeon Socket P+ LGA4189 2TB DRAM 36x3.5HS

Mfg Part Number:  SSG-540P-E1CTR36H

Special Note: Jun 07, 2021
NCNR; If you do not have loading facility, please contact our CST for special handling service.

Image may not reflect the actual item.
Price: $5,267.07 + Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Jun 20, 2025
No Sales Tax except these states
, PO and Wire.
Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number SSG540PE1CTR36H
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line SuperServer
Product Model 540P-E1CTR36H
Product Name UP Storage SuperServer SSG-540P-E1CTR36H
Product Type Server Barebone System
Processor
Number of Processors Supported 1
Processor Socket Socket LGA-4189
Processor Supported Xeon Platinum
Processor Supported Xeon Bronze
Processor Supported Xeon Gold
Processor Supported Xeon Silver
64-bit Processing Yes
Chipset
Chipset Manufacturer Intel
Chipset Model C621A
Memory
Maximum Memory Supported 2 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Total Number of Memory Slots 8
Storage
Supported Storage Drive Interfaces Serial ATA III
Supported Storage Drive Interfaces PCI Express
Supported Storage Drive Interfaces SAS-3
Supported Storage Drive Types SSD
Supported Storage Drive Types HDD
Controllers
Controller Type Serial ATA/600
Controller Type 12Gb/s SAS
Controller Type NVMe
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Ethernet Technology Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 36
Number of 3.5" Bays 36
Total Number of Expansion Slots 4
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 2
Number of M.2 Interfaces 1
Interfaces/Ports
Total Number of USB Ports 9
Number of USB 3.2 Gen 1 Ports 3
Number of Onboard USB 2.0 Ports 2
Network (RJ-45) Yes
Number of Network (RJ-45) Ports 3
Number of VGA Ports 1
Power Description
Input Voltage 120 V AC
Input Voltage 230 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1200 W
Frequency 60 Hz
Frequency 50 Hz
Physical Characteristics
Color Family Black
Product Color Black
Form Factor Rack-mountable
Rack Height 4U
Height 7"
Width 17.2"
Depth 27.5"
Weight (Approximate) 66.50 lb
Miscellaneous
Package Contents
  • UP Storage SuperServer SSG-540P-E1CTR36H
  • 1 x 4U Chassis
  • 1 x Super X12SPI-TF Motherboard
  • 1 x 8 int 12Gb/s ports, x8 Gen4, ROC- LP, 240 HDD w/exp,RoHS
  • 1 x 8-port Mini SAS HD Int-to-Ext Cable Adapter W/LP Bracket
  • 1 x 12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH
  • 1 x 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD
  • 4 x 9" 4 PIN FAN PWS EXTENSION CORD, PBF
  • 1 x 4 Pin to 4 Pin I2C Cable, 65cm, 26AWG, 4 Wires, Pinout 1-1
  • 1 x Slimline x8 (STR) to 2x MiniSAS HD x4,65CM,100 OHM,RoHS
  • 4 x Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s
  • 1 x Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s [FCI]
  • 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF
  • 2 x US POWER CORD 16AWG, PB FREE
  • 7 x PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,37CM,22AWG,5A/pin,RoHS
  • 1 x Standard I/O Shield for X12SPi with EMI Gasket
  • 1 x 540P-E1CTR36L/H Quick Reference Guide
  • 1 x License key for enabling OOB BIOS management
  • 1 x 2U Passive CPU Heat Sink for X12 Generation Intel Whitley and Cedar Island Platforms
  • 2 x AC-DC 1200W, Titanium Level, Redundancy, 1U, PMBUS 1.2, +12V/+5Vsb, 336x76x40 mm,HF,RoHS/REACH
  • 1 x 24pin standard output with 5V high current 100Amp power distributor board for SC847
  • 7 x 80x80x38 mm, 13.5K RPM, Optional Middle Cooling Fan for 2U Ultra Series Servers (Hot-swappable Version of FAN-0162L4)
  • 1 x Chassis transfer board for SC826
  • 36 x Black gen 5.5 hot-swap 3.5" HDD tray
  • 1 x SC847B LP MB Tray assembly,HF,RoHS/REACH
  • 1 x Rail set, quick/quick, default for 4U 17.2" W
  • 1 x Rail screw bag
  • 1 x SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB
Warranty
Limited Warranty 1 Year
Additional Warranty Information

Supermicro provides a three-year warranty for labor and one-year warranty for parts.
