OPTICON

OPTICON PR11WU1-00 BARCODE SCANNERS,PR-11 2D CMOS IMAGER PASSPORT SCANNER, USB, WHITE

Mfg Part Number:  PR11WU1-00
Image may not reflect the actual item.
Price: $373.60 + Free Shipping
Quantity:
More to Come
Last Updated: Aug 28, 2025
No Sales Tax except these states
, PO and Wire.

The PR-11 is a high speed, omnidirectional 2D imager barcode scanner that incorporates Opticon's latest digital imaging technology. The PR-11 is used as a standalone scanner for hands-free, ultra-fast 1D or 2D barcode scanning. Designed to seamlessly scan many forms of identification including optimized reading of MRTD (Machine Readable Travel Document), the PR-11 is ideal in applications such as customs, airport security and identification control. Product highlights of the PR-11 include:

  • High speed 2D CMOS imager-omnidirectionally scans up to 120 frames per second
  • Rapidly scans and decodes 1D and 2D barcodes, from both MRTD (Machine Readable Travel Document) and from mobile device screens
  • Incorporates MDI-4100 scan engine for improved scanning of low quality barcodes and providing exceptional motion tolerance for moving applications
  • Data editing program function captures up to 16 codes on multiple images simultaneously
  • Ideal size for scanning different forms of identification
  • Compact form factor: 5.57" x 5.07" x 4.3" (w x h x d)
  • Trigger modes: manual and auto-trigger
  • Flexible cable outlet: 4 directions
  • Communication interfaces: USB (HID, COM)
  • Available in black or white
  • Anti-microbial coating (white version)
  • Two year warranty


Main Specification
General Information
Manufacturer Opticon Sensors Europe
Manufacturer Part Number PR11WU1-00
Manufacturer Website Address http://www.opticon.com
Brand Name Opticon
Product Model PR-11
Product Name PR-11 2D CMOS Imager Passport Scanner
Product Type Barcode Scanner
Technical Information
Connectivity Technology Cable
Scanning Capability 2D
Scanning Capability 1D
Barcode Symbology Supported

1D:

  • JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/ Plessey, UK/Plessey, S-Code, Telepen, Tri-Optic

2D:

  • Aztec Code, Aztec Runes, Composite codes, Codablock F, Data Matrix (ECC200), Maxi Code, MicroPDF417, Micro QR Code, PDF417, QR Code OCR: MRTD comply to ICAO Doc 9303 standard (Passport, Visa-A/B, Official Travel Documents1/2)

Postal Code:

  • Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, Dutch KIX code, UK Postal, Australian Postal, Postal JPN, POSTNET, PLANET
Light Source LED
Image Sensor Type Imager
Image Sensor Type CMOS
Scan Mode Trigger
Features Vibration
Reading Angle (Skew) 360°
Reading Angle (Pitch) 360°
Reading Angle (Roll) 360°
Image Formats JPEG
Image Formats BMP
Maximum Ambient Light 100000 lux
Drop Specification

2.46 ft (0.75 m) drop onto concrete surface
Image Sensor Resolution 1280 x 800
Interfaces/Ports
Host Interface USB
Environmental Conditions
Operating Temperature 23°F (-5°C) to 113°F (45°C)
Storage Temperature -22°F (-30°C) to 140°F (60°C)
Humidity (Non-condensing) 10% to 90%
Physical Characteristics
Color Family White
Product Color White
Height 5.1"
Width 5.6"
Depth 4.3"
Weight (Approximate) 1.15 lb
Miscellaneous
Application/Usage Identification Control
Application/Usage Custom
Application/Usage Airport Security
Application/Usage Passport
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 2 Year
product information
