B+B SmartWorx/Advantech
B+B SmartWorx/Advantech ESRP-CMS-TPC1751 TPC-1751T-E3BE ACP THIN CLIEN
Mfg Part Number: ESRP-CMS-TPC1751 , Item #: 4356086
, PO and Wire.
Introduction
Realize the true value of thin client and centralized management technologies with Advantech's ThinManager compatible industrial thin clients. ACP's ThinManager, the leading thin client solution for the factory floor, and Advantech's industrially hardened thin client hardware provide a unique solution for centralized management of factory floor applications.
ESRP-CMS-TPC1751 is the next-generation model of Advantech's 17" industrial panel PC. Equipped with a 17" XGA TFT LED LCD, low-power Intel® Atom™ E3845, 1.91GHz, quadcore processor, and 4 GB of DDR3L SDRAM, TPC-1251T(B) delivers high-performance computing in a compact, fanless system. For enhanced durability to satisfy diverse industrial automation applications, ESRP-ESRP-CMS-TPC1751 supports a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and features a true-flat 5-wire resistive touchscreen with IP66-rated front panel, die-cast aluminum alloy front bezel, and 100 x 100 VESA mount kit.
| General Information | |
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | ESRPCMSTPC1751 |
| Manufacturer Website Address | http://www.advantech.com |
| Brand Name | Advantech |
| Product Model | ESRP-CMS-TPC1751 |
| Product Name | 17" Intel Atom Multi-Touch PC ACP Ready ThinClient |
| Product Type | Thin Client |
| Processor | |
| Processor Type | Atom |
| Processor Model | E3845 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 1.91 GHz |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Standard Memory | 4 GB |
| Maximum Memory Supported | 8 GB |
| Memory Technology | DDR3L SDRAM |
| Display & Graphics | |
| Screen Size | 17" |
| Display Screen Type | Active Matrix TFT LCD |
| Screen Mode | SXGA |
| Screen Resolution | 1280 x 1024 |
| Touchscreen | Yes |
| Backlight Technology | LED |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 3 |
| Number of USB 3.0 Ports | 1 |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Supply Wattage | 58 W |
| Physical Characteristics | |
| Height | 13.5" |
| Width | 16.2" |
| Depth | 2.2" |
| Weight (Approximate) | 11.24 lb |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Taiwan Restriction of Hazardous Substances (Taiwan RoHS) |
