HPE
HPE JL675A#B2E ARUBA 6100 48G CL4 4SFP+ SWCH L6-20 220V
Mfg Part Number: JL675A#B2E , Item #: 4314847
, PO and Wire.
Aruba 6100 Switch Series
The Aruba CX 6100 Switch Series is modern family of entrylevel access switches ideal for enterprise branch offices andSMB networks. Optimized for reliable, simple and secure access, the CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile and cloud applications.
The CX 6100 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 370W of PoE to support IoT devices such as security cameras and wireless APs, and includes acompact and fanless model ideal for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the CX 6100 also simplifies ownership with no software licensing requirements..
| General Information | |
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | JL675A#B2E |
| Manufacturer Website Address | http://www.hpe.com |
| Brand Name | HPE |
| Product Series | 6100 |
| Product Name | 6100 48G Class4 PoE 4SFP+ 370W Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet PoE |
| Port/Expansion Slot Details | 4 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4.0 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Network & Communication | |
| Layer Supported | 3 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 370 W |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Power Source | Power Supply |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 30.60 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Wall Mountable |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 12" |
| Weight (Approximate) | 11.07 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
Cable Management
Modules
HPE Aruba - SFP (mini-GBIC) transceiver module - GigE - 1000Base-SX - LC multi-mode - up to 1640 ft - for OfficeConnect 1820, HPE Aruba 2930F 12, 2930F 8G, 2930M 40, 6300, 6405 48, 6405 96, 64XX
HPE Aruba - SFP (mini-GBIC) transceiver module - GigE - 1000Base-LX - LC single-mode - up to 6.2 miles - for OfficeConnect 1820, HPE Aruba 2930F 12, 2930F 8G, 2930M 40, 6300, 6405 48, 6405 96, 64XX
HPE Aruba - SFP+ transceiver module - 10 GigE - 10GBase-SR - SFP+ / LC multi-mode - up to 984 ft - for HPE Aruba 2930F 12, 2930F 8G, 2930M 24, 2930M 40, 6300, 6405 48, 6405 96, 64XX, 72XX, 83XX
HPE Aruba - SFP+ transceiver module - 10 GigE - 10GBase-LR - SFP+ / LC single-mode - up to 6.2 miles - for HPE Aruba 2930F 12, 2930F 8G, 2930M 24, 2930M 40, 6300, 6405 48, 6405 96, 64XX, 83XX
Mounting Kits
HPE Aruba X414 Universal 4-post - Rack mounting kit - 1U - for HPE Aruba 2540 24G 4SFP+, 2540 24G PoE+ 4SFP+, 2540 48G 4SFP+, 2540 48G PoE+ 4SFP+
