SUPERMICRO

Supermicro SV AS-1024US-TRT 1U SP3 AMD EPYC7002 8TB DDR4 1000W Brown Box

Mfg Part Number:  AS-1024US-TRT
Image may not reflect the actual item.
Price: $3,379.59 + Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Jun 03, 2026
No Sales Tax except these states
, PO and Wire.

A+ Servers

A+ Servers are Your Best Choice!

A+ Servers' Benefits:

  • Uncompromising Quality Control
  • Most Comprehensive Line of Rackmount/Tower Servers
  • Redundant Components (virtually eliminating system downtime)
  • Best Price/Performance Ratio
  • Superior Product Design (all under one roof)
  • Consistently First-to-Market
  • Maximized Performance
  • Reduced Total Cost of Ownership (TCO)
  • Top-Notch Finishing Materials
  • 3-Year Limited Warranty
  • 24-Hour Server Support

These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end PC/server industry. After all, Supermicro provides the most outstanding product line in the industry. Their proven high level of quality and performance has made A+ Servers the platform of choice for supercomputer clusters and enterprise databases as well as business-critical, front-end server applications.

Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number AS-1024US-TRT
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line A+ Server
Product Model 1024US-TRT
Product Name A+ Server 1024US-TRT
Packaged Quantity 1
Product Type Server Barebone System
Processor
Number of Processors Supported 2
Processor Socket Socket SP3
Processor Supported EPYC
Chipset
Chipset Manufacturer AMD
Memory
Maximum Memory Supported 8 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Total Number of Memory Slots 32
Controllers
Controller Type Serial ATA/600
Controller Type 12Gb/s SAS
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 4
Number of 3.5" Bays 4
Total Number of Expansion Slots 4
Number of PCI Express x16 Slots 4
Interfaces/Ports
Total Number of USB Ports 3
Number of USB 3.0 Ports 3
Power Description
Input Voltage 230 V AC
Input Voltage 120 V AC
Number of Power Supplies Installed 1
Maximum Power Supply Wattage 1000 W
Physical Characteristics
Form Factor Rack-mountable
Rack Height 1U
Height 1.7"
Width 17.2"
Depth 29"
Weight (Approximate) 26 lb
Miscellaneous
Package Contents
  • A+ Server 1024US-TRT
  • 1 x Super H12DSU-iN Motherboard
  • 1 x 1U Chassis
  • 1 x 1U Ultra Riser with 2-port 10GBase-T RJ45, based on Intel Carlsville X710-AT2, with 1 PCI-E 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8),RoHS
  • 1 x 4-port 1U SAS3 12Gbps Hybrid backplane, support up to 4x 3.5-inch SAS3/SATA3/NVMe Storage Devices
  • 1 x 8 Pin Female to 2x RA(Right Angle) Big 4 Pin Female Power
  • 1 x [NR] Slimline x8 (LE) to 2x Oculink x4 (STR),INT,55/44CM,85
  • 1 x [NR]Slimline x8 (LE) to 2x Oculink x4 (STR),INT,55/44CM,85 O
  • 1 x [NR] Slimline X8 (LE) to 4x SATA,INT,P0 520mm,P1 440mm,P2 52
  • 1 x 1U Ultra Mylar cable channel for X12
  • 1 x 1U LHS WIO Riser card with two PCI-E 4.0 x16 slots,HF,RoHS
  • 1 x 1U RHS WIO Riser card with one PCI-E 4.0 x16 slot,HF,RoHS
  • 2 x 1U Passive CPU Heat Sink for AMD Socket SP3 Processors
  • 2 x 1U 1000W Redundant Power Supply 73.5mm width Titanium Level,RoHS/REACH
  • 8 x 40x40x56 mm, 23.3K-20.3K RPM, Counter-rotating Fan
  • 1 x Ultra I/O Rear Window for SC819U, 119U-T tool-less chassis(i2XT)
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 3 Year
