Supermicro SV AS-1124US-TNRP 1U SP3 AMD EPYC7002 8TB DDR4 1200W Brown Box

Mfg Part Number:  AS-1124US-TNRP
Image may not reflect the actual item.
Price: $3,449.69 + Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: May 11, 2026
No Sales Tax except these states
, PO and Wire.
Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number AS-1124US-TNRP
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line A+ Server
Product Model 1124US-TNRP
Product Name A+ Server 1124US-TNRP (Black)
Product Type Server Barebone System
Processor
Number of Processors Supported 2
Processor Socket Socket SP3
Processor Supported EPYC
Chipset
Chipset Manufacturer AMD
Memory
Maximum Memory Supported 8 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Total Number of Memory Slots 32
Storage
Supported Storage Drive Interfaces SAS-3
Supported Storage Drive Interfaces Serial ATA III
Controllers
Controller Type 12Gb/s SAS
Controller Type Serial ATA/600
Display & Graphics
Graphics Controller Manufacturer ASPEED
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 12
Total Number of Expansion Slots 4
Number of PCI Express x16 Slots 4
Interfaces/Ports
Total Number of USB Ports 4
Number of USB 3.0 Ports 4
Number of SATA Interfaces 12
Number of SAS Interfaces 12
Number of VGA Ports 1
Power Description
Input Voltage 120 V AC
Input Voltage 230 V AC
Maximum Power Supply Wattage 1200 W
Physical Characteristics
Color Family Black
Product Color Black
Form Factor Rack-mountable
Rack Height 1U
Height 1.7"
Width 17.2"
Depth 29.1"
Miscellaneous
Package Contents
  • A+ Server 1124US-TNRP (Black)
  • 1 x Super H12DSU-iN Motherboard
  • 1 x CSE-119UHTS-R1K22HP-A chassis
  • 1 x 1U Ultra Riser with 2-port 10GBase-T RJ45 & 2-port 10G SFP+, based on Intel Carlsville X710-AT2, with 1 PCI-E 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8).,RoHS
  • 1 x 1U Hybrid BPN for 12x2.5"; SAS3/SATA3/NVMe Storage Devices
  • 1 x [NR] CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,30CM,28AWG,RoHS
  • 1 x PWR EXT,2X4F/P4.2 TO TWO 2X2F/P4.2,CPU(5,12V),65/65CM,18AWG
  • 1 x [NR] PWR EXT,2X4F to 2x2, 42CM,18AWG, 8A/pin,RoHS
  • 1 x [NR] Slimline x8 (LE) to Slimline x8 (RE),43CM,85 OHM
  • 1 x [NR] Slimline x8 (STR) to Slimline x8 (RE/LE),FFC,54CM,85 OH
  • 1 x [NR] Slimline x8 (RE) to Slimline x8 (LE),58CM,85 OHM
  • 1 x [NR] Slimline x8 (LE) to Slimline x8 (LE),60CM,85 OHM
  • 1 x [NR] Slimline x8 (LE) to 2x Slimline x4 (RA),FFC,63/65CM,85
  • 1 x 1U LHS WIO Riser card with two PCI-E 4.0 x16 slots,HF,RoHS
  • 1 x 1U RHS WIO Riser card with one PCI-E 4.0 x16 slot,HF,RoHS
  • 2 x 1U Passive CPU Heat Sink for AMD Socket SP3 Processors
  • 2 x 1U 1200W/800W Titanium Redundant Power Supply CRPS 73.5x203x40mm,RoHS/REACH
  • 8 x 40x40x56 mm, 23.3K-20.3K RPM, Counter-rotating Fan
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 3 Year
