BLACK BOX KVXLCHDP-200 KVM EXTENDER OVER CATX 4K DUAL-HEAD HDMI/DISPLAYPORT

Mfg Part Number:  KVXLCHDP-200
Image may not reflect the actual item.
Price: $1,108.97
Quantity:
In Stock: 39
Last Updated: Dec 04, 2025
No Sales Tax except these states
, PO and Wire.

The KVX HDMI/DisplayPort Dual Head KVM Extender lets you control a server or computer over a standard CAT5 or CAT6 UTP network cable connection at distances of up to 328 feet (100 meters). This extender also supports 4K video. PC connection cables are included with this product, making it a solution that is ready to use right out of the box.

Unlike any other product on the market, the KVX HDMI/DP Dual Head KVM Extender features mixed input to support HDMI or DisplayPort sources and output to dual HDMI displays.

You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console. KVX Dual Head is the perfect low-cost solution for transportation control centers, medical facilities, industrial warehouses, and extended workstations.

KVX Dual Head is equipped with an RS-232 serial channel that connects to a serial terminal or to serial devices, such as touchscreens and barcode scanners. It eliminates the need for traveling back and forth between the local computer and remote console, making it an efficient and flexible solution.

KVX Dual Head also includes local video, allowing access to an additional monitor at the transmitter side. It's perfect for any situation that requires monitoring of connected PCs.

This extender is TAA compliant and backed by free lifetime technical support. KVX Dual Head is ideal for applications that require the console to be in a conveniently accessible location while the system equipment needs to reside in a safe place - away from dust, dirt, and harsh environmental influences. It also provides a cost-effective way of keeping sensitive data, such as financial and personal information, safe in a heavily secured data center while still allowing remote access to users.

Main Specification
General Information
Manufacturer Black Box Corporation
Manufacturer Part Number KVXLCHDP-200
Manufacturer Website Address http://www.blackbox.com
Brand Name Black Box
Product Series KVX
Product Model KVXLCHDP-200
Product Name KVXLCHDP-200 KVM Extender
Product Type KVM Extender
Technical Information
Connectivity Technology Wired
Number of Computers Supported 2
Number of Local Users Supported 1
Maximum Operating Distance 328.08 ft
Device Type KVM Extender
Video
Graphic Mode 4K
Maximum Video Resolution 3840 x 2160
Interfaces/Ports
Network (RJ-45) Yes
USB Yes
HDMI Yes
DisplayPort Yes
Number of HDMI Ports 4
Number of Network (RJ-45) Ports 4
Number of USB Ports 5
Power Description
Input Voltage 5 V DC
Physical Characteristics
Form Factor Desktop
Transmitter Height 1.10"
Transmitter Width 7.15"
Transmitter Depth 3.25"
Receiver Height 1.10"
Receiver Width 7.15"
Receiver Depth 3.25"
Transmitter Weight (Approximate) 13.44 oz
Receiver Weight (Approximate) 13.60 oz
Miscellaneous
Package Contents
  • 1 x Transmitter
  • 1 x Receiver
  • 2 x 5V, 2A Power Supplies (includes US, EU, UK plug types)
  • 2 x HDMI cables 1.2m (4 ft.)
  • 2 x DisplayPort cables 1.2m (4 ft.)
  • 1 x 3.5mm audio cable 1.8m (6 ft.)
  • 1 x USB-B to USB-A cable 1.8m (6 ft.)
  • 2 x Deskmounting brackets (with screws)
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Environmental Compliance Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin Taiwan
TAA Compliant Yes
Warranty
Limited Warranty 2 Year
