Eaton

Eaton 9PX2200GRT-L 9PX 2200 208V RT LI-ION

Mfg Part Number:  9PX2200GRT-L
Image may not reflect the actual item.
Price: $3,142.11
Quantity:
In Stock: 2
Last Updated: May 02, 2025
No Sales Tax except these states
, PO and Wire.

2.2kVA/2kW/208V Long-Term Battery Backup for IT Installations and Edge Networks

This 9PX rack-mount online double-conversion UPS system provides reliable, low-maintenance battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage valuable IT equipment or destroy data. Ideal for locations that are difficult to access or infrequently maintained, the 9PX2200GRT-L is an efficient "set it and forget it" solution. It's ideal power management for education, commercial, financial or healthcare networking components, including Cisco switches and servers.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages

The hot-swappable maintenance-free lithium-ion battery modules have a service life of 8 to 10 years. They allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Exclusive ABM technology increases battery life by 50 percent and closely monitors battery health to provide advanced notice when batteries need replacing. These lithium iron phosphate (LFP) batteries provide 80 to 120 percent more runtime at full load than equivalent lead-acid UPS systems, while weighing up to 40 percent less, reducing the overall UPS weight.

Supports External Batteries for Scalable Extended Runtime

For mission-critical applications demanding continuous uptime, the UPS supports the connection of up to four expanded battery modules (9PXEBM72RT-L, sold separately) for hours of extended runtime.

Optional Gigabit Network Interface Offers 24/7 Remote Access

The Network-M3 network card (sold separately or as a network card bundle) enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. UPS firmware can also be flashed remotely through the Network-M3 without dropping the load, so you don't have to plan for downtime. The card meets both UL 2900-1 and IEC 62443-4-2 standards for cybersecurity, which were developed to address the vulnerability of connected devices to known malware/exploits and to protect business from these risks. The optional Environmental Monitoring Probe Gen 2 (EMPDT1H1C2, sold separately) provides a variety of environmental monitoring capabilities, including temperature and humidity conditions.

Main Specification
General Information
Manufacturer Eaton Corporation
Manufacturer Part Number 9PX2200GRT-L
Manufacturer Website Address http://www.eaton.com
Brand Name Eaton
Product Series 9PX
Product Name 9PX UPS
Product Type Double Conversion Online UPS
Technical Information
Plug/Connector Type NEMA L6-20P
Receptacle Type IEC 60320 C19
Receptacle Type IEC 60320 C13
Receptacle Detail 8 x IEC 60320 C13
Receptacle Detail 2 x IEC 60320 C19
Application/Usage Industrial Automation System
Application/Usage Electronic
Application/Usage Healthcare
Application/Usage IT
Application/Usage University
Application/Usage Medical
Application/Usage Edge Computing
Power Description
Load Capacity (VA) 2200 VA
Load Capacity (Watt) 2000 W
Input Voltage 230 V AC
Input Frequency 60 Hz
Waveform Type True Sine Wave
Management
Network Management Network-M3 Card
Network Management Relay-MS Card
Network Management ModBus-MS Card
Controls/Indicators
Status Indicators Grpahical Display
Interfaces/Ports
Serial Port Yes
Network (RJ-45) Yes
USB (HID Compliant) Port Yes
Battery Information
Battery Chemistry Lithium Ion (Li-Ion)
Hot Swappable Yes
Replaceable Battery Yes
Environmental Conditions
Sound Emission 47 dB
Physical Characteristics
Color Family Dual Color
Product Color Black
Product Color Silver
Height 3.4"
Width 17.3"
Depth 23.8"
Rack Height 2U
Form Factor Rack/Tower
Weight (Approximate) 48.72 lb
Miscellaneous
Package Contents
  • 9PX UPS
  • Quick Start Guide
  • Safety Instructions
  • USB Communciation Cable
  • RS-232 Serial Communication Cable
  • 4-post Rail for 19-inch Enclosures
  • Software Leaflet
  • 2 x Pedestals for Tower Poition
Warranty
Limited Warranty 5 Year
