The FortiGate 800D series provides an application-centric, scalable and secure SD-WAN solution with next generation firewall (NGFW) capabilities for mid-sized to large enterprises deployed at the campus or enterprise branch level. Protects against cyber threats with system-on-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution. Fortinet's Security-Driven Networking approach provides tight integration of the network to the new generation of security.
Security
Performance
Certification
Networking
Management
Security Fabric
| General Information | |
| Manufacturer | Fortinet, Inc |
| Manufacturer Part Number | FG-800D-BDL-824-36 |
| Manufacturer Website Address | http://www.fortinet.com |
| Brand Name | Fortinet |
| Product Line | FortiGate |
| Product Series | 800D |
| Product Model | FG-800D |
| Product Name | FortiGate FG-800D Network Security/Firewall Appliance |
| Product Type | Network Security/Firewall Appliance |
| Technical Information | |
| Functionality | Intrusion Prevention |
| Firewall Protection Supported | Botnet Detection |
| Firewall Protection Supported | Web Content Filtering |
| Firewall Protection Supported | Virus Protection |
| Firewall Protection Supported | IoT Security |
| Firewall Protection Supported | Outbreak Prevention |
| Firewall Protection Supported | Threat Protection |
| Firewall Protection Supported | Anti-spam |
| Firewall Protection Supported | Secure IPsec VPN Connectivity |
| Firewall Protection Supported | Intrusion Prevention |
| Firewall Protection Supported | SSL Encrypted Traffic Protection |
| Firewall Protection Supported | Antivirus |
| Firewall Protection Supported | Endpoint Protection |
| Firewall Protection Supported | Policy Enforcement |
| Firewall Protection Supported | Deep Inspection Firewall |
| Firewall Protection Supported | DNS Security |
| Firewall Protection Supported | Cloud Sandboxing |
| Firewall Protection Supported | SSL Inspection |
| Firewall Protection Supported | Application Control |
| Firewall Protection Supported | Malware Protection |
| Firewall Throughput | 36 Gbit/s |
| Encryption Standard | AES (256-bit) |
| Encryption Standard | SHA-256 |
| Number of VPN Supported | 5000 |
| Connectivity Technology | Wired |
| Interfaces/Ports | |
| Total Number of Ports | 24 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 24 |
| Media & Performance | |
| VPN Throughput | 2.50 GB/s |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Standard | 10GBase-X |
| Network Standard | 10/100/1000Base-T |
| Network Standard | 1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 10 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Expansion Slot Type | SFP+ |
| Number of SFP Slots | 8 |
| Number of SFP+ Slots | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Power Consumption | 187 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.8" |
| Width | 17" |
| Depth | 16.4" |
| Weight (Approximate) | 19 lb |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Network |
| Application/Usage | Security |
| Application/Usage | Data Center |
| Application/Usage | Enterprise |
| Application/Usage | Business |
| Certifications & Standards |
|
| Warranty | |
| Limited Warranty | 1 Year |
| Support/Service Duration | 3 Year |
| Support/Service Type | 24X7 Cspp Ent Protection |
