The ECW5410-L is a concurrent dual-band 802.11ac Wave 2 high-density access point. Featuring dual 4x4 Multi-User MIMO (MU-MIMO) radios, the ECW5410-L can simultaneously support up to 600 Mbps and 1.73 Gbps data rates for both 2.4GHz and 5GHz bands, far surpassing the throughput of the latest 802.11ac Wave 1 access points. It provides a Gigabit LAN port for Ethernet-capable network devices and a built-in Bluetooth Low Energy (BLE) beacon that can be used for targeted marketing campaigns. The combination 802.11ac Wave 2 MU-MIMO technology and 4x4 spatial streams makes the ECW5410-L a top choice for high-density environments such as stadiums, arenas, and conference rooms.
General Information | |
Manufacturer | Edge-Core Networks Corporation |
Manufacturer Part Number | ECW5410L |
Manufacturer Website Address | http://www.edge-core.com |
Brand Name | Edge-Core |
Product Model | ECW5410-L |
Product Name | ECW5410-L Indoor Access Point |
Product Type | Wireless Access Point |
Technical Information | |
Wireless LAN Standard | IEEE 802.11ac |
Network Band | Dual Band |
Frequency Band | 2.40 GHz |
Frequency Band | 5 GHz |
Total Number of Antennas | 5 |
Number of Internal Antennas | 5 |
Indoor/Outdoor | Indoor |
Wireless Transmission Speed | 2.30 Gbit/s |
MIMO Technology | Yes |
Data Encryption | Yes |
Encryption Standard | WPA |
Encryption Standard | TKIP |
Encryption Standard | WEP |
Encryption Standard | AES |
Encryption Standard | WPA2 |
Interfaces/Ports | |
Ethernet Technology | Gigabit Ethernet |
Number of Network (RJ-45) Ports | 2 |
PoE PD Port | Yes |
USB | Yes |
USB Standard | USB 2.0 |
Management Port | Yes |
Power Description | |
Power Consumption | 22.50 W |
Physical Characteristics | |
Form Factor | Wall Mountable |
Form Factor | Ceiling Mountable |
Antenna Form Factor | Internal |
Height | 1.3" |
Width | 7.5" |
Depth | 7.5" |
Weight (Approximate) | 1.34 lb |
Miscellaneous | |
Package Contents |
|
