VERTIV
VERTIV HMX6500R-400 DH-DP RX AUDIO USB 2.0 VDI
Mfg Part Number: HMX6500R-400 , Item #: 4156303
Image may not reflect the actual item.
Price: $2,407.28
+ Free Shipping
Quantity:
In Stock: 56
Last Updated: Nov 28, 2025
No Sales Tax except these states
, PO and Wire.
The Vertiv Avocent HMX6500R is a high performance KVM receiver that delivers KVM and Virtual Machine (VM) access without requiring additional hardware or compromise on KVM functionality. Users can switch instantly between unlimited virtual and physical machines or gives users instant access to take control of unlimited sources directly from their own individual workstation. By incorporating Virtual Desktop Infrastructure (VDI) protocols into the receiver, the Avocent HMX6500R allows all operators to access all machines in a more efficient way. Instead of adding a new transmitter every time a user needs access to a new virtual session, an administrator can easily configure the management system to enable permissions. It is ideal for demanding applications such as broadcast, control rooms, and collaborative environments.
Main Specification
| General Information | |
| Manufacturer | Vertiv |
| Manufacturer Part Number | HMX6500R-400 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Brand Name | Vertiv AVOCENT |
| Product Line | HMX |
| Product Series | 6000 |
| Product Model | HMX6500R-400 |
| Product Name | HMX 6500R | High Performance KVM Receiver (HMX6500R-400) |
| Packaged Quantity | 1 |
| Product Type | KVM Extender Receiver |
| Technical Information | |
| Connectivity Technology | Wired |
| KVM Technology | Digital |
| Number of Local Users Supported | 1 |
| Device Type | High Performance KVM |
| Video | |
| Maximum Video Resolution | 2560 x 1600 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| PS/2 Port | No |
| USB | Yes |
| Digital Audio/Video | Yes |
| DVI | No |
| Headphone | Yes |
| Microphone | Yes |
| HDMI | No |
| VGA | No |
| DisplayPort | Yes |
| Proprietary Interface | Yes |
| Number of HDMI Ports | 0 |
| Number of VGA Ports | 0 |
| Number of Network (RJ-45) Ports | 2 |
| Number of PS/2 Ports | 0 |
| Number of USB Ports | 6 |
| Number of DVI Ports | 0 |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Consumption | 20 W |
| Physical Characteristics | |
| Rack Height | 1U |
| Form Factor | Rack-mountable |
| Receiver Height | 11.20" |
| Receiver Width | 9.60" |
| Receiver Depth | 5.70" |
| Receiver Weight (Approximate) | 5.50 lb |
| Miscellaneous | |
| Platform Supported | Linux |
| Platform Supported | PC |
| Platform Supported | Mac |
| Country of Origin | United Kingdom |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
