HITACHI

HITACHI HGST RD 1ES0173 240TB 4U60 G2 8x12Gbps SAS 2x1650W PSU nTAA ISE Bare

Mfg Part Number: 1ES0173 , Item #: 4146916

Special Note: Jun 22, 2020
NCNR; If you do not have loading facility, please contact our CST for special handling service.

Image may not reflect the actual item.

Price: $20,656.86 + Free Shipping

Quantity:

In Stock/Mfg Direct Ship

Last Updated: Sep 01, 2025

No Sales Tax except these states

, PO and Wire.

When data centers need storage expansion that delivers low power and high capacity with high-availability, they rely on the HGST 4U60G2 Storage Platform. This high density, scalable, and cost-effective design includes up to 60 Ultrastar® 3.5-inch drive modules in a 4U enclosure, supports up to 8 hosts with SAS 12Gb/s performance, and delivers enterprise-class serviceability with hot-swappable components.

This integrated platform is qualified, tested and certified to support a broad range of HGST HDDs. It's available with SAS drives for high-availability (HA) applications, with SATA drives for cost-optimized applications, and can be configured with up to twelve (12) 800GB SSDs to create separate performance tiers within the platform.

Main Specification

General Information
Manufacturer	Western Digital Corporation
Manufacturer Part Number	1ES0173
Manufacturer Website Address	http://www.wdc.com
Brand Name	HGST
Product Model	4U60G2
Product Name	4U60G2 Storage Platform
Product Type	Drive Enclosure
Technical Information
Number of Hard Drives Supported	60
Number of Hard Drives Installed	24
Total Hard Drive Capacity Installed	240 TB
Controllers
Non-RAID Mode	JBOD
I/O Expansions
Number of Total Expansion Bays	60
Number of 3.5" Bays	60
Interfaces/Ports
Host Interface	12Gb/s SAS
Physical Characteristics
Cooling Fan	Yes
Form Factor	Rack-mountable
Rack Height	4U
Height	6.9"
Width	16.7"
Depth	34.7"
