Features:
"Up-the-coax" type signal may be sent over the same wire pair at distances up to 750ft (225m).
The unparalleled interference rejection ability of the Model NV-3213 Hub allows video signals to co-exist in the same wire bundle as telephone, datacom, or low-voltage power circuits. Perfect for larger CCTV installations where port density and camera number growth are prevalent. With built-in transient protection, damaging voltage spike problems are eliminated.
- High-Density 19" 1U high enclosure features 32 ports
- Use with any NVT passive transceiver or hub as a rack-mountable passive transceiver for full motion CCTV at distances up to 750ft (225m)
- Use with any NVT DigitalEQTM Hub or active receiver as a rack-mountable passive transmitter for distances up to 3,000ft (1km) Use with any NVT StubEQTM for distances up to 1,500ft (460m)
- RJ45 video connectivity with optional NV-RJ45A RJ45 to screw terminal adaptors (included)
- No power required
- Exceptional interference rejection
- Built-in transient protection
- Supports "up-the coax" type control signal up to 750ft (225m)
- Compatible with qualified UTP cameras
- Includes thirty-two 2ft (60cm) coax jumper cables and rackmount hardware
- Limited lifetime warranty
"Up-the-coax" type signal may be sent over the same wire pair at distances up to 750ft (225m).
The unparalleled interference rejection ability of the Model NV-3213 Hub allows video signals to co-exist in the same wire bundle as telephone, datacom, or low-voltage power circuits. Perfect for larger CCTV installations where port density and camera number growth are prevalent. With built-in transient protection, damaging voltage spike problems are eliminated.
Main Specification
| General Information | |
| Manufacturer | Phybridge, Inc |
| Manufacturer Part Number | NV-3213 |
| Manufacturer Website Address | http://www.phybridge.com |
| Brand Name | NVT Phybridge |
| Product Model | NV-3213 |
| Product Name | 32-Channel Video Transceiver Hub |
| Product Type | Video Extender Transceiver |
| Technical Information | |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 3280.84 ft |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 8 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Twisted Pair Cable Standard | Category 5 |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Form Factor | Desktop |
| Form Factor | Rack-mountable |
| Miscellaneous | |
| Package Contents |
|
| Warranty | |
| Limited Warranty | Lifetime |
