AddOn ADD-SC-LC-MB8MS9SMF SC/LC M/M PATCH CBL 8M YELLOW OS2 RISER FIBER

This is an 8m SC to LC Yellow OS2 Simplex Microboot, Snagless OFNR (Riser-Rated) SMF Fiber Patch Cable. OS2 fiber optic cable is a high-performance single-mode fiber designed for long-distance data transmission, making it ideal for businesses requiring reliable and fast network connections over longer distances up to 200kilometers. With low signal loss and the ability to support 1G to 100G speeds, ensuring efficient communication across offices, data centers, or industrial facilities. OFNR riser fiber cable jackets are designed for vertical installations in building risers, providing fire-resistant protection to ensure safe data transmission between floors. These cables meet strict safety standards, making them ideal for businesses that need reliable, in-building network infrastructure without the risk of fire spreading through conduits. The Micro boot connector option features an ultra-compact design, reducing the overall footprint of the connector for easier handling in tight spaces or high-density installations. This solution is perfect for businesses needing streamlined fiber connections while maximizing space in racks and panels. Our cables are TIA compliant, ensuring performance for all networking needs.

General Information
Manufacturer	AddOn
Manufacturer Part Number	ADD-SC-LC-MB8MS9SMF
Manufacturer Website Address	http://www.addoncomputer.com
Brand Name	AddOn
Product Name	Fiber Optic Patch Network Cable
Packaged Quantity	1 Piece
Product Type	Network Cable
Technical Information
Cable Type	Fiber Optic
Cable Characteristic	Patch Cable
Cable Configuration	Straight-through
Fiber Optic Mode	Single-mode
Fiber Type	Simplex
Fiber Optic Cable Core/Cladding Specification	9/125 µm
Fiber Category	OS2
Cable Length	26.25 ft
Maximum Distance	656167.98 ft
Connector Type on First End	SC Network - Male
Connector Gender on First End	Male
Connector on First End Details	1 x SC Network - Male
Connector Type on Second End	LC Network - Male
Connector Gender on Second End	Male
Connector on Second End Details	1 x LC Network - Male
Conductor	Fiber
Shielding	No
Jacket Type	Riser
Jacket Type	OFNR
Device Supported	Network Device
Boot Type	Microboot
Boot Type	Snagless
Bend Insensitivity	G.657.A1
Features	Fire Resistant
Features	Fire Proof
Features	Stranded
Features	Ultra Physical Contact (UPC)
Physical Characteristics
Color Family	Yellow
Product Color	Yellow
Connector Color	Blue
Color Details	Connector 1 Color: Blue Connector 2 Color: Blue
Jacket Material	Polyvinyl Chloride (PVC)
Height	0.1"
Width	0.3"
Weight (Approximate)	0.40 lb
Shipping Height	5"
Shipping Width	2.75"
Shipping Weight (Approximate)	8 oz
Miscellaneous
Additional Information	Compatible OEM: Industry Standard Strand Count: 1 Polarity: Type A-A Insertion Loss Grade: Grade C Outer Diameter: 2.0mm
Application/Usage	Data Center
Application/Usage	Data Transmission
Application/Usage	Industrial
Application/Usage	Indoor
Application/Usage	Business
Application/Usage	Office
Certifications & Standards	TIA Compliant
Country of Origin	China
TAA Compliant	No
Warranty
Limited Warranty	Lifetime
